GE IS420UCSBH1A 、緊湊型Mark VIe控制器、UCSB 控制器模塊
IS420UCSBH1A
IS420UCSBH1A 產品描述:
General Electric的Mark VIe控制器IS420UCSBH1A類似于UCSC控制器,所有相同的一般信息都可以應用于UCSB模型。IS420UCSBH1A型號通常是緊湊型獨立控制器,用于幫助處理控制器邏輯。
IS420UCSBH1A控制器是通用電氣制造的第一款UCSB控制器,是Mark VIe控制安全系統系列的一部分。該控制器類似于UCSC控制器,雖然它沒有相同的硬件,但操作該控制器所需的軟件幾乎相同。根據GEH-6725 Mark VIe和Mark VIeS,控制設備HazLoc說明指南,IS420UCSBH1A控制器被標記為Mark VIe、LS2100e和EX2100e控制器。該控制器還有一個特定的微處理器,安裝在該設備中的微處理器是600 MHz EP80579 Intel處理器。
IS420UCSBH1A供電所需的電氣/電源額定值,額定值如下,最小電壓為18直流電,最大電壓為30伏直流電,標稱額定功率為24和28伏直流電。此設備使用的最大額定電流為1.5 ADC。
安裝時,需要通過多項認證才能將IS420UCSBH1A控制器安裝在危險和非危險場所。例如,當安裝在ATEX Zone 2,Group IIC時,需要的認證是UL DEMKO 12 ATEX 1114875X。有關安裝在I類、2區、IIC組、非危險和I類、2區、A、B、C和D組的控制器的所有認證都是相同的,這些位置的認證要求是UL E207685。
IS420UCSBH1A優點
UCSB 控制器具有以下優勢:
單模塊
內置電源
無需跳線設置
無電池
無風扇
更小的面板占地面積
閃存可以輕松更新
UCSB 控制器安裝在面板中,并通過板載 I/O 網絡 (IONet) 接口與 I/O 包進行通信。IONet 是一種私有專用以太網,僅支持 Mark 控制 I/O 模塊和控制器。
特征
微處理器::600 MHz Intel EP80579
內存:256 MB DDR2 SDRAM,帶糾錯碼 (ECC)、閃存支持的 SRAM、NAND 閃存大小為 2 GB
操作系統:QNX Neutrino
重量:2.4磅
IS420UCSBH1A
IS420UCSBH1A Product Description:
The Mark VIe controller IS420UCSBH1A from General Electric is similar to the UCSC controller, and all the same general information can be applied to the UCSB model. The IS420UCSBH1A model is typically a compact independent controller used to assist in handling controller logic.
The IS420UCSBH1A controller is the first UCSB controller manufactured by General Electric and is part of the Mark VIe Control Safety System series. This controller is similar to the UCSC controller, although it does not have the same hardware, the software required to operate the controller is almost the same. According to the GEH-6725 Mark VIe and Mark VIeS, the IS420UCSBH1A controller is labeled as a Mark VIe, LS2100e, and EX2100e controller based on the HazLoc instruction manual for control equipment. The controller also has a specific microprocessor, which is a 600 MHz EP80579 Intel processor installed in the device.
The electrical/power ratings required for IS420UCSBH1A power supply are as follows, with a minimum voltage of 18 DC and a maximum voltage of 30 V DC, and nominal rated power of 24 and 28 V DC. The maximum rated current used by this device is 1.5 ADC.
During installation, multiple certifications are required to install the IS420UCSBH1A controller in hazardous and non hazardous locations. For example, when installed in ATEX Zone 2, Group IIC, the required certification is UL DEMKO 12 ATEX 1114875X. All certifications for controllers installed in Class I, Zone 2, IIC group, non hazardous and Class I, Zone 2, A, B, C, and D groups are the same, and the certification requirements for these locations are UL E207685.
IS420UCSBH1A Advantages
The UCSB controller has the following advantages:
Single module
Built in power supply
No need for jumper settings
No battery
No fan
Smaller panel footprint
Flash memory can be easily updated
The UCSB controller is installed in the panel and communicates with the I/O pack through the onboard I/O network (IONet) interface. IONet is a private dedicated Ethernet that only supports Mark controlled I/O modules and controllers.
features
Microprocessor: 600 MHz Intel EP80579
Memory: 256 MB DDR2 SDRAM with error correction code (ECC), SRAM supported by flash memory, NAND flash memory size of 2 GB
Operating System: QNX Neutrino
Weight: 2.4 pounds
