0-57170 FlexPak Plus 驅動板
0-57170是Reliance Electric制造的調節器模塊，屬于FlexPak Plus系列。系統中每個控制器支持一個0-57170調節器模塊。0-57170的型號為14C650。
數字驅動模塊在較大的驅動器控制器中充當設備驅動程序。這部分運行操作驅動器控制器的軟件，并充當硬件設備和使用它的操作系統之間的轉換器。
當安裝正確時，數字驅動模塊應該有發射脈沖，并且應該輸出到驅動控制器的電源立方。調節器模塊應該輸出到數字驅動模塊。脈沖變壓器初級側有電阻，脈沖波形應為+11.2v。電源立方體47和45的讀數應該是0-240的230 VAC控制器和0-500的460 VAC控制器。
如果需要排除故障，首先測試穩壓器模塊輸出到數字驅動模塊。如果一切正常，測試數字驅動器發射脈沖。為安全起見，請務必關閉電源，然后打開主斷開連接，松開調節器/數字驅動模塊組件(每個角落有四個螺釘)。接下來，將示波器公共連接到穩壓器模塊上的引腳57。將示波器探頭連接到位于7A或數字驅動板的脈沖變壓器初級側的電阻上。重新接通電源并切換到START位置。將速度鍋轉到完全打開的位置。如果發射脈沖不發生，讀數不能在14A, 10A, 11A, 13A和8A，更換數字驅動模塊。
0-57170 FlexPak Plus 驅動板
The?0-57170 is a Regulator Module manufactured?by Reliance Electric which belongs to the FlexPak Plus Series. One?0-57170 Regulator Module is supported per controller in a system. The?0-57170 has the model number 14C650.
The Digital Driver Module works as a device driver in the larger drive controller. This piece runs the software that operates the drive controller and acts as a translator between the hardware device and the operating systems that use it.
When installed correctly, the Digital Driver Module should have firing pulses and should be outputting to the power cubes of the drive controller. The Regulator Module should be outputting to the Digital Driver Module. There are resistors on the primary side of the pulse transformers, and the pulse waveform should be +11.2v. The reading across power cubes 47 and 45 should be 0-240 for 230 VAC controllers and 0-500 for 460 VAC controllers.
If troubleshooting is needed, first test the regulator module for output to the digital driver module. If all is working there, test the digital driver for firing pulses. Be sure to turn the power off for safety, then open the main disconnect and loosen the Regulator/Digital Driver Module assembly (four screws in each corner). Next, connect the scope common to Pin 57 on the Regulator Module. Connect the scope probe to the resistor on the primary side of the pulse transformer located at 7A or the Digital Driver Board. Turn the power back on and switch into the START position. Turn SPEED POT to the full on position. If firing pulses do not occur and readings cannot be obtained at 14A, 10A, 11A, 13A, and 8A, replace the Digital Driver Module.
