描述

125840-02 電源模塊可以實現升壓變換、降壓變換、交直流轉換等功能

125840-02電源模塊的作用主要體現在以下幾個方面：

隔離：在強電弱電隔離、IGBT隔離驅動、浪涌隔離保護、雷電隔離保護等方面，電源模塊起到安全隔離的作用。同時，它還可以實現噪聲隔離，包括模擬電路與數字電路隔離、強弱信號隔離，以及接地環路消除等。

保護：電源模塊具有短路保護、過壓保護、欠壓保護、過流保護等功能，并可以提供其他保護措施。

電壓變換：電源模塊可以實現升壓變換、降壓變換、交直流轉換等功能，滿足各種電壓變換需求。

穩壓：電源模塊具備交流市電供電、遠程直流供電、分布式電源供電系統、電池供電等功能，提供穩定的電壓輸出。

降噪：電源模塊具有有源濾波功能，有效降低噪聲。

此外，一些電源模塊產品可以通過TRIM或ADJ（可調節）輸出引腳對輸出電壓進行一定范圍內的調節。這種調節通?？梢酝ㄟ^(guò)電位器或電阻實現，調節范圍通常為±10%。對于需要更高要求的電源系統，應增加輸入濾波網絡。同時，為了防止輸入電源瞬態高壓損壞電源模塊，建議在輸入端接瞬態吸收二極管并配合保險絲使用。

在應用時，125840-02 需要注意電源模塊的遙控開關電路操作方式，以及電源模塊的組合方式。其中，并聯擴容可以將相同電源模塊輸出端并聯，以增強輸出能力；冗余熱備份并聯則是將相同的電源模塊輸出端通過二極管后并聯，以提高電源系統的可靠性；串聯擴容則是將相同模塊輸出端串聯，使輸出電壓倍增、功率增加。

125840-02 電源模塊可以實現升壓變換、降壓變換、交直流轉換等功能

125840-02 Power module functions are mainly reflected in the following aspects:

Isolation: In terms of strong and weak current isolation, IGBT isolation drive, surge isolation protection, lightning isolation protection, etc., the power module plays a safe isolation role. At the same time, it can also achieve noise isolation, including analog circuit and digital circuit isolation, strong and weak signal isolation, and ground loop elimination.

Protection: The power module provides short-circuit protection, overvoltage protection, undervoltage protection, overcurrent protection, and other protection measures.

Voltage conversion: The power module can achieve boost conversion, buck conversion, AC/DC conversion and other functions to meet various voltage conversion requirements.

Voltage regulator: The PSU provides AC mains power supply, remote DC power supply, distributed power supply system, and battery power supply to provide stable voltage output.

Noise reduction: The power module has the active filter function to effectively reduce noise.

In addition, some power module products can adjust the output voltage within a certain range through TRIM or ADJ (adjustable) output pins. This adjustment can usually be achieved by a potentiometer or resistor, and the adjustment range is usually ±10%. For power systems that require higher requirements, input filtering networks should be added. At the same time, in order to prevent the transient high voltage of the input power supply from damaging the power module, it is recommended to connect the transient absorption diode at the input end and use it with the fuse.

In the application, 125840-02 need to pay attention to the remote control switch circuit operation mode of the power module, and the combination mode of the power module. In parallel expansion, the output terminals of the same power module can be connected in parallel to enhance the output capability. The redundant thermal backup parallel is to parallel the output end of the same power module through the diode to improve the reliability of the power system. In series expansion, the output end of the same module is connected in series to multiply the output voltage and increase the power.
