1326AB-B730E-M2L 高性能交流伺服電機
基本伺服電機描述
1326AB-B730E-M2L伺服電機是Allen-Bradley設計的高性能三相無刷交流同步電機系列，可滿足伺服系統應用的嚴格要求。該系列標準dac伺服電機可與1391交流伺服控制器配合使用。這些電機與所選放大器的性能參數列在第8頁。典型的速度-轉矩曲線(見第9頁)描述了這些電機和控制器組合的運行包絡。
每臺電機具有以下標準特性:
?永磁轉子增加伺服響應。
?三相正弦繞線定子場的熱量直接傳遞到環境，并在低速平穩運行。
?無刷解析器提供位置，換相和速度反饋信息。這也提供了耐用性，在惡劣的環境下，沒有車載電子馬達。1391四B(可選)編碼器輸出(高達2048 ppr)是通過解析器反饋產生的。
?100%連續額定輸出扭矩在失速(零rpm)。
?精確平衡0.0005“(0.0127毫米)總峰值位移。
?垂直軸上下安裝。
?TENV結構。
?IP65等級(當與軸密封選項一起使用時)，可承受惡劣環境。電機是防塵的，能夠承受脈動水射流，沒有液體進入電機。重要:當使用外部安裝的編碼器/解析器反饋或鼓風機包時，1326AB電機失去IP 65額定值。
?電機繞組中的常閉熱開關(1A時額定115V AC, 1A時額定24V DC)提供熱過載指示。
?環保密封的電源和反饋電纜封裝。電源和解析器反饋電纜可按標準(柔性)，軌道(多柔性)或延長長度(ES)訂購。
?MIL規格連接器是標準的。
?性價比高的鐵氧體磁鐵。
?UL認可的絕緣系統(文件# E57948)。
1326AB-B730E-M2L 高性能交流伺服電機
Basic Servomotor Description
The 1326AB-B730E-M2L Servomotors are a family of high performance, three-phase,brushless AC synchronous motors designed by Allen-Bradley to meet thestringent requirements of servo system applications. This series of standardAC servomotors can be used with 1391 AC Servo Controllers. The performance parameters of these motors with selected amplifiers are listed onpage 8. The typical speed-torque curves (see page 9) depict the operational envelope of these motor and controller combinations.
Each motor has the following standard features:
? Permanent magnet rotor for increased servo response.
? Three-phase sinusoidal wound stator field for direct transfer of heat toambient, and smooth operation at low speeds.
? Brushless resolver supplies position, commutation & velocity feedbackinformation. This also provides durability in harsh environments by nothaving on-board electronics in the motor. 1391 A Quad B (optional)encoder output (up to 2048 ppr) is generated via resolver feedback.
? 100% continuous rated output torque at stall (zero rpm).
? Precision balance of 0.0005” (0.0127 mm) total peak-peakdisplacement.
? Vertical shaft up or down mounting.
? TENV construction.
? IP65 rated (when used with the Shaft Seal option) to withstand harshenvironments. Motor is dust-tight and able to withstand pulsating waterjets without liquid entering the motor.Important: 1326AB motors lose the IP 65 rating when externallymounted encoder/resolver feedback or blower packages are used.
? Normally closed thermal switch in the motor winding (rated 115V AC at1A, 24V DC at 1A) provides thermal overload indication.
? Environmentally sealed power and feedback cable packages. Power andresolver feedback cables can be ordered as standard (flex), track(multi-flex) or extended length (ES).
? MIL spec connectors are standard.
? Ferrite magnets for cost effective performance.
? UL recognized insulation system (file # E57948).
