描述

1336-BDB-SP74C? ? 柵極驅動PCB

制造商:羅克韋爾自動化
品牌:艾倫-布拉德利
產品系列:1336
產品類型:備件
裝配級別:1級;主要的組裝
描述:柵極驅動PCB
兼容驅動器:plus (S)， Force (T)
電壓:575v AC
頻率:50 – 60hz
功率等級:7.5 HP
溫度范圍:0-60攝氏度

1336- bdb – sp7c板是用于Allen-Bradley公告1336可調頻率驅動器的Allen-Bradley備件板。該1336- bdb – sp7c板是用于1336 Plus (S)和Force (T)驅動器的PCB柵極驅動板。PCB在575伏交流電壓下工作，輸出功率為7.5馬力。正常工作頻率為50 ~ 60赫茲。1336-BDB-SP7C柵極驅動PCB打開和關閉IGBT制動器，并為主控板和隔離板供電。它位于主控板和機箱之間，帶有專用的閘板驅動板安裝板。該安裝板便于維護和拆卸柵極驅動PCB。使用標識清晰的跳線與主板連接，以消除接線錯誤。當出現錯誤顯示(如EE INIT READ 53警告)或即使施加電源也不存在總線電壓時，請考慮更換PCB柵極驅動器。

專用端子排TB1允許連接幀號B(額定功率為1 ~ 15馬力和240伏，1 ~ 30馬力和380伏，或1 ~ 20馬力和600伏)的驅動器的輸入和輸出。更高馬力額定的驅動器(幀尺寸C, D, E, G和H)在驅動器底部安裝了TB1端子排，需要進行輸入和輸出電源連接。1336-BDB-SP7C PCB板卸載時需要注意的事項。通過測量+DC和-DC兩端的電壓，確認母線電壓為零(0)伏。在拆卸之前，請確認鎖定電源已從驅動器斷開?？商娲?336-BDB-SP7C板的零件號為1336- convv – sp7a (Ser)。A到C)或1336-BDB-SP7D柵極驅動板。

1336-BDB-SP74C? ?柵極驅動PCB

Manufacturer: Rockwell Automation
Brand: Allen-Bradley
Product Family: 1336
Product Type: Spare part
Assembly Level: Level 1; Major Assembly
Description: Gate Driver PCB
Compatible Drives: Plus (S), Force (T)
Voltage: 575 V AC
Frequency: 50 – 60 Hz
Power Rating: 7.5 HP
Temperature Range: 0-60 degrees Celsius

The?1336-BDB-SP7C board?is an Allen-Bradley spare part?board for the Allen-Bradley Bulletin 1336 adjustable frequency drives. ? This 1336-BDB-SP7C board?is a PCB gate drive board for use with 1336 Plus (S) and Force (T) drives. The PCB operates with 575 Volts AC voltage with a 7.5 Horsepower output power rating. The normal operating frequency is 50 to 60 Hertz. The?1336-BDB-SP7C gate drive PCB turns the IGBT brake on and off and it supplies power to the main control and isolation boards.? It is located between the main control board and chassis, with a dedicated gate drive board mounting plate. This mounting plate enables easy?maintenance and removal of the gate drive PCB. The?unit is connected to the mainboard with the use of jumper wires with clear identifications to eliminate wiring errors. Consider replacing the PCB gate drive when there is an error display like the EE INIT READ 53 warning or when the bus voltage is not present even if power is applied.

Dedicated terminal block TB1 allows the connection of Input and output for drives with Frame Size B (rated at 1 to 15 Horsepower and 240 Volts,?1 to 30 Horsepower and 380 Volts, or?1 to 20 Horsepower?and 600 Volts). Higher horsepower-rated?drives (frame sizes C, D, E, G, and H) have TB1 terminal blocks?installed on the bottom of the drive where both the input and output power connections need?to be made. Caution must be observed when performing the uninstallation of the 1336-BDB-SP7C PCB. Verify that the bus voltage has Zero (0) volts by measuring the voltage across the?+DC and -DC terminals. ?? Confirm that the lock-out power is disconnected from the drive before disassembly. Alternate part numbers that can serve as a replacement to the 1336-BDB-SP7C board are 1336-CONV-SP7A (Ser. A to C) or 1336-BDB-SP7D gate drive?board.
