描述

136719-01 可接收來自接近探頭或磁性拾音器的輸入信號

增強型Keyphasor模塊是一種改進的3500系統模塊，136719-01用于提供擴展的Keyphasor信號處理能力。與以前的設計相比，它具有更強的按鍵信號處理能力，同時在形式、配合和功能方面保持了與現有Keyphasor模塊的完全向下兼容性，可用于傳統系統。

該模塊接收來自近程探頭或磁性拾音器的輸入信號，并將該信號轉換為數字鍵控信號，該信號指示軸上的鍵相標記何時與鍵相傳感器重合。3500機械保護系統在正常配置中最多可接受四個Keyphasor信號，在配對配置中最多可接受八個Keyphasor信號。

增強型Keyphasor模塊136719-01具有以下功能特點：

半高雙通道模塊設計，提供兩個通道的信號處理能力。

可接收來自接近探頭或磁性拾音器的輸入信號，并將這些信號轉換為數字鍵相器信號。

具備擴展的鍵相器信號處理能力，能夠提供更精確的鍵相標記識別。

與傳統Keyphasor模塊保持完全向下兼容，可在傳統系統中使用。

具備高可靠性和穩定性，能夠在惡劣環境中穩定運行。

可用于各種工業自動化應用場景，如風機、泵、壓縮機等設備的狀態監測和故障診斷。

可與其他監測設備、控制器和軟件進行集成，實現遠程監控和數據傳輸。
易于使用和維護，為用戶提供了便捷的操作體驗。

136719-01 可接收來自接近探頭或磁性拾音器的輸入信號

The Enhanced Keyphasor module is an improved 3500 system module, 136719-01 to provide extended Keyphasor signal processing capabilities. Compared to previous designs, it has stronger keystroke signal processing capabilities, while maintaining full backward compatibility with existing Keyphasor modules in terms of form, fit and function, and can be used in legacy systems.

The module receives an input signal from a short-range probe or magnetic pickup and converts this signal into a digital keying signal that indicates when the key phase mark on the shaft coincides with the key phase sensor. The 3500 mechanical protection system accepts up to four Keyphasor signals in a normal configuration and up to eight Keyphasor signals in a paired configuration.

The enhanced Keyphasor module 136719-01 has the following features:

Half-height dual-channel module design provides signal processing capability of two channels.

Input signals from proximity probes or magnetic pickups can be received and converted into digital key phaser signals.

Extended key phase signal processing capabilities to provide more accurate key phase marker recognition.

Fully backward compatible with traditional Keyphasor modules, it can be used in traditional systems.

With high reliability and stability, it can operate stably in harsh environments.

It can be used in various industrial automation application scenarios, such as condition monitoring and fault diagnosis of fans, pumps, compressors and other equipment.

It can be integrated with other monitoring devices, controllers and software for remote monitoring and data transfer.
Easy to use and maintain, providing users with a convenient operation experience.
