1738-IB16DM12 A輸入模塊

Allen-Bradley 1738-IB16DM12 ArmorPoint系列A輸入模塊具有16個非隔離輸入，5伏的斷開狀態電壓和1.5毫安的斷開狀態電流。每個輸入最大傳感器源電流為50毫安，每個模塊最大傳感器源電流為800毫安。本模塊現場供電電壓范圍為10 ~ 28.8伏，最大28.8伏時功耗為2.7瓦。1738-IB16DM12模塊在最大28.8伏時的散熱為9.2英熱單位(BTU) /小時，具有50伏的連續隔離電壓，具有增強絕緣類型。模塊自帶LED指示燈，供終端用戶判斷模塊狀態，有16個黃色指示燈表示輸入/輸出狀態，1個綠/紅指示燈表示網絡狀態，1個綠/紅指示燈表示模塊狀態，1個紅色指示燈表示故障狀態。

1738-IB16DM12模塊的更通用規格包括符合IP 65、66、67和69K標準的外殼等級(標記時)和5伏75毫安的最大點總線電流。1738-IB16DM12模塊的環境規格包括工作溫度范圍為-4 ~ 140華氏度，存儲溫度范圍為-40 ~ 185華氏度。本模塊的相對濕度范圍為5% ~ 95%(無冷凝)。該模塊的工作沖擊額定值為30g，非工作沖擊額定值為50g。它的排放等級為1類A級，符合CISPR 11標準。它的振動等級是5克，在10到50赫茲。該模塊的尺寸為4.72 x 2.83 x 4.25英寸，或120 x 72 x 42毫米。它的重量為10.24盎司或290克。

1738-IB16DM12 A輸入模塊

The Allen-Bradley 1738-IB16DM12 ArmorPoint Series A Input Module has 16 nonisolated inputs, 5 Volts of off-state voltage, and 1.5 Milliamps of off-state current. The maximum sensor source current per input is 50 Milliamps and the maximum sensor source current per module is 800 Milliamps. This module’s field power supply voltage range is 10 to 28.8 Volts and its power dissipation is 2.7 Watts at 28.8 Volts (maximum). The 1738-IB16DM12 module has a thermal dissipation of 9.2 British Thermal Units (BTU) per hour at 28.8 Volts maximum and a continuous isolation voltage at 50 Volts with a reinforced insulation type. LED indicators are included with the module, allowing the end-users to determine the status of the module, and there are 16 yellow LEDs indicating the input/output status, 1 green/red LED indicating the network status, 1 green/red LED indicating the module status, and 1 red LED for the fault status.

More general specifications for the 1738-IB16DM12 module include an enclosure rating that meets the IP 65, 66, 67, and 69K standards (when marked) and a maximum PointBus current of 75 Milliamps at 5 Volts. The environmental specifications on the 1738-IB16DM12 module include an operating temperature range between -4 and 140 degrees Fahrenheit and a storage temperature range between -40 and 185 degrees Fahrenheit. The relative humidity range on this module is between 5 and 95% (non-condensing). This module has an operating shock rating of 30 g, with a non-operating shock rating of 50 g. It has an emissions rating of Group 1, Class A, which is compliant with the CISPR 11 standards. Its vibration rating is 5 g at 10 to 50 Hertz. This module has dimensions of 4.72 x 2.83 x 4.25 inches, or 120 x 72 x 42 millimeters. It has a weight of 10.24 ounces or 290 grams.
