描述

1756-A7 7槽ControlLogix機架

1756-A7是來自于ControlLogix可編程自動化控制器（PAC）平臺的七（7）插槽機箱。這款機箱是開放式設備，沒有用于保護的外殼，其設計特點主要體現在其頂部和底部都只有2個安裝卡舌，這使得它在安裝和部署時具有更大的靈活性。

在功能上，1756-A7是將ControlLogix控制系統構建為機箱的重要組件。它提供背板連接，允許將模塊安裝在提供的模塊插入插槽中。此外，它還裝有電源的安裝插槽，位于機箱的最左側，支持超薄、標準和電源的安裝。

關于其硬件結構，1756-A7的設計允許安裝或不安裝2個SEM螺釘。在沒有SEM螺釘?shù)那闆r下，除了2個平墊圈和2個分鎖墊圈外，還需要2個星墊圈。同時，如果沒有SEM螺釘，則需要4個十字螺釘；而如果與SEM螺釘一起使用，則只需要2個十字螺釘。

1756-A7 7槽ControlLogix機架

The 1756-A7 is a seven (7) slot chassis from the ControlLogix Programmable Automation Controller (PAC) platform. The chassis is an open device with no protective housing, and its design features are mainly reflected in the fact that it has only 2 mounting clips on the top and bottom, which gives it greater flexibility when installing and deploying.

Functionally, the 1756-A7 is an important component in building the ControlLogix control system as a chassis. It provides a backplane connection that allows the module to be installed in the module insertion slot provided. In addition, it has a power supply installation slot, located on the far left side of the case, supporting ultra-thin, standard and power supply installation.

Regarding its hardware construction, the 1756-A7 is designed to allow for the installation or non-installation of 2 SEM screws. In the absence of SEM screws, 2 star washers are required in addition to 2 flat washers and 2 split lock washers. At the same time, if there are no SEM screws, four phillips screws are required; If used with SEM screws, only 2 phillips screws are required.
