描述

1756-L1 增強型模擬 I/O 模塊

安裝在 ControlLogix? 機架中
需要可拆卸端子塊 (RTB) 或 Bulletin 1492 接線接口模塊 (IFM) 來進行所有現場接線
包含固有的時間戳功能，適用于事件序列 (SOE) 應用項目
提供 EtherNet/IP? 通信，包括 CIP Security? 和冗余功能
可實現全面的 I/O 診斷，從而能夠檢測系統故障和現場故障
可帶電插拔 (RIUP)，便于維護
提供電子鍵控功能，有助于防止替換錯誤
在 Studio 5000 Logix Designer? 應用程序中包含 I/O 向?qū)?，可快速方便地進行模塊配置
1756-L1? ?ControlLogix CIP 安全 I/0 模塊

支持 Compact GuardLogix? 5380 或 GuardLogix 5580 控制臺
提供高達（包括）SIL3 和 PLe 的功能安全等級
支持 CIP Safety 信息轉發和路由功能
用作 5580 GuardLogix 控制器的本地 I/O 或分布式 I/O
提供更快的響應時間
使用 Logix Designer 應用程序版本 32
提供數字輸入模塊：IB16S – 16 通道（各個等級均為 SIL 3）
提供數字輸出模塊：OBV8S – 8 通道（各個等級均為 SIL 3）
包括合規性標記：TüV，UL, IECEx, ATEX, CE, Marine, FM
ControlLogix 數字量 I/O 模塊

提供各種電壓
每個模塊提供 8 至 32 個點
具備隔離和非隔離模塊類型
包含通道級故障狀態輸出
可實現直接連接或機架優化通信
對選定模塊進行現場診斷
1756 ControlLogix 模擬量 I/O 模塊

包含輸入、輸出和組合模塊
提供熱電偶和熱電阻模塊
包含模塊級別數據報警
提供工程單位整定
提供實時通道采樣
提供電子模塊匹配，可通過軟件配置
包含機械可拆卸端子塊匹配，用戶自定義
逐通道配置電壓、電流或 2 線變送器電流源流型
逐通道配置熱電阻或熱電偶
ControlLogix 1756 帶隔離的模擬量 I/O 6 通道模塊將于 2017 年 3 月 31 日停產，不再銷售。建議客戶根據 6 通道至 8 通道 1756 模擬量模塊遷移指南遷移至 1756-L1? ?隔離模擬量 I/O 8 通道模塊
1756-L1? ?ControlLogix 特殊功能 I/O 模塊

包含可配置的流量計模塊
提供高速計數器模塊
提供可編程限位開關模塊
1756-L1? ControlLogix 可拆卸端子塊 (RTB)

實現工廠接線與 I/O 模塊之間的靈活互連
包含螺絲夾或彈簧夾端子
不附帶 I/O 模塊；必須單獨訂購
1756 HART 模擬隔離 I/O 模塊

提供通道間隔離
逐通道提供 HART 總線調制解調器，從而提高 HART 總線數據更新速度
通過用戶自定義配置文件提供基本現場設備配置
幫助消除在使用隔離模塊時對現場隔離屏障的需要
提供 8 或 16 通道密度模塊
1756-L1? ?增強型模擬 I/O 模塊

可提高準確性、可重復性、穩定性和精度
包含隔離 8 通道以及非隔離 12 和 16 通道模塊，可在整個運行溫度范圍內實現穩定運行
無需現場校準
使用 24 位設計可提高精度
包含每通道狀態和故障指示燈指示
提供 SIL 1、系統功能 2，且已通過類型認證，可應用在 ControlLogix SIL 2 架構中
提供仿真模式，可幫助客戶從 6 通道應用項目進行升級
1756 通信模塊

在 1756-L1? 機架中對用戶、設備和網絡實施基于網絡的訪問控制
提供冗余功能
提供安全模塊，用于對控制器和服務器之間共享的重要信息進行加密，以防止篡改
1756-L1? ? 計算模塊

可通過背板提供對 ControlLogix 控制器的高速訪問
集成的 DisplayPort? 可實現高清 5100 工業監視器的直接連接
可在 ControlLogix 機架中提供計算能力

1756-L1 增強型模擬 I/O 模塊

Mounts in the ControlLogix? rack
A removable terminal block (RTB) or Bulletin 1492 Wiring Interface Module (IFM) is required for all field wiring
Includes built-in timestamp functionality for event sequence (SOE) applications
Provides EtherNet/IP? communications, including CIP Security? and redundancy capabilities
Comprehensive I/O diagnostics enable detection of system failures and field failures
Live pluggable (RIUP) for easy maintenance
Electronic keying is provided to help prevent replacement errors
I/O wizards are included in the Studio 5000 Logix Designer? application for quick and easy module configuration
1756-L1 ControlLogix CIP secure I/0 module

Compact GuardLogix? 5380 or GuardLogix 5580 console is supported
Functional safety levels up to (including) SIL3 and PLe are available
Supports CIP Safety information forwarding and routing
Local or distributed I/O for use as the 5580 GuardLogix controller
Provides faster response times
Use the Logix Designer application version 32
Digital input modules available: IB16S-16 channels (SIL 3 for all grades)
Digital output modules available: OBV8S-8 channels (SIL 3 for all grades)
Includes compliance marks: TUV, UL, IECEx, ATEX, CE, Marine, FM
ControlLogix Digital I/O module

Various voltages available
Each module provides 8 to 32 points
Both isolated and non-isolated module types are available
Contains channel-level fault status output
Direct connection or rack-optimized communication is possible
Field diagnostics for selected modules
1756 ControlLogix Analog I/O module

Contains input, output, and combination modules
Thermocouple and thermal resistance modules available
Contains module-level data alarms
Provide engineering unit setting
Provides real-time channel sampling
Provides electronic module matching and can be configured through software
Contains mechanical detachable terminal block matching, user-defined
Configure voltage, current, or 2-wire transmitter current source flow pattern on a channel-by-channel basis
Configure thermal resistors or thermocouples on a channel-by-channel basis
The ControlLogix 1756 analog I/O 6-channel module with isolation will be discontinued on March 31, 2017 and will no longer be sold. Customers are advised to migrate to the 1756-L1 isolated analog I/O 8-channel module according to the 6-to-8-channel 1756 Analog Module Migration Guide
1756-L1 ControlLogix Special Function I/O module

Includes configurable flow meter modules
High speed counter module available
Programmable limit switch module available
1756-L1 ControlLogix Detachable Terminal Block (RTB)

Flexible interconnection between factory wiring and I/O modules
Includes screw clamp or spring clamp terminals
No I/O module; Must be ordered separately
1756 HART analog isolation I/O module

Provides isolation between channels
HART bus modems are provided on a channel-by-channel basis to improve HART bus data update speed
You can configure basic onsite devices through user-defined profiles
Helps eliminate the need for on-site isolation barriers when using isolation modules
Available in 8 or 16 channel density modules
1756-L1 Enhanced analog I/O module

Improves accuracy, repeatability, stability and precision
Includes isolated 8-channel and non-isolated 12 and 16-channel modules for stable operation over the entire operating temperature range
No field calibration required
Use 24-bit design to improve accuracy
Contains each channel status and fault indicator
Provides SIL 1, System function 2, and is type-certified for use in the ControlLogix SIL 2 architecture
Simulation mode is available to help customers upgrade from 6-channel application projects
1756 Communication module

Implement network-based access control for users, devices, and networks in the 1756-L1 rack
Provides redundancy functions
Provides a security module for encrypting important information shared between the controller and server to prevent tampering
1756-L1 Compute Module

High-speed access to the ControlLogix controller is provided through the backplane
The integrated DisplayPort? enables direct connectivity of HD 5100 industrial monitors
Computing power is available in the ControlLogix rack
