描述

1756-L55 ControlLogix處理器模塊

1756-L55是ControlLogix系列中的一個處理器模塊，由Allen-Bradley/Rockwell Automation設計和生產。這款模塊是ControlLogix工業環境中常用的組件，以其高質量和頂級性能而聞名。

該處理器模塊在溫度、濕度、振動和沖擊耐受性方面滿足不同的IEC 60068額定值要求，顯示出其卓越的耐用性和可靠性。在背板電流方面，該模塊在24伏特直流電時的背板電流為0.014安培，而在5.1伏特直流電時為1.23至1.25安培。此外，它的額定功率為5.6至5.7瓦，熱耗散為每小時19.1至19.4 BTU。

在功能方面，1756-L55處理器模塊具有基本絕緣類型和30V的連續隔離電壓，并經過測試，可承受707V DC 60s的電壓。此外，它還具有特定的傳導RF抗擾度要求，并能在一定的存儲和工作溫度范圍內正常工作。

ControlLogix結構體系是一個集成了多種控制功能的技術平臺，包括順序控制、運動控制、傳動及過程控制等。與傳統的可編程控制器不同，ControlLogix系統具有模塊化的設計，允許用戶根據具體應用選擇適當?shù)膬?nèi)存量、控制器個數和網絡類型。這種柔性結構使得在同一機架內可以使用多個控制器、網絡及I/O模塊。

同時，ControlLogix控制器還提供了一種可升級的解決方案，能夠?qū)Υ罅康妮斎胼敵鳇c(diǎn)進行尋址?？刂破骺梢圆迦隒ontrolLogix輸入輸出機架的任一槽位中，并且多個控制器能插在同一個機架中，相互之間通過機架背板進行通訊但互相獨立工作。此外，ControlLogix控制器還支持多種通信協議，如RS-232-C（DF1/DH-485協議）、DeviceNet、DH+、ControlNet、EtherNet/IP等，以實現與其他計算機或其他處理器的通信。

總的來說，1756-L55 ControlLogix處理器模塊是一款高性能、可靠且靈活的工業自動化組件，能夠滿足各種復雜的控制需求。

1756-L55 ControlLogix處理器模塊

The 1756-L55 is a processor module in the ControlLogix family, designed and produced by Allen-Bradley/Rockwell Automation. This module is a common component in ControlLogix industrial environments and is known for its high quality and top performance.

The processor module meets different IEC 60068 rating requirements in terms of temperature, humidity, vibration and shock resistance, demonstrating its exceptional durability and reliability. In terms of backplane current, the module has a backplane current of 0.014 amps at 24 volts DC, compared to 1.23 to 1.25 amps at 5.1 volts DC. In addition, it has a power rating of 5.6 to 5.7 watts and a heat dissipation of 19.1 to 19.4 BTU per hour.

In terms of functionality, the 1756-L55 processor module has a basic insulation type and a continuous isolation voltage of 30V, and has been tested to withstand a voltage of 707V DC 60s. In addition, it has specific conductive RF immunity requirements and can operate properly over a certain storage and operating temperature range.

The ControlLogix architecture is a technology platform that integrates multiple control functions, including sequence control, motion control, transmission and process control. Unlike traditional programmable controllers, the ControlLogix system has a modular design that allows users to select the appropriate amount of memory, number of controllers, and network type for their specific application. This flexible structure makes it possible to use multiple controllers, networks and I/O modules in the same rack.

At the same time, the ControlLogix controller also provides an upgradeable solution for addressing a large number of input and output points. Controllers can be inserted into any slot of the ControlLogix input/output rack, and multiple controllers can be inserted into the same rack and communicate with each other through the rack backplane but work independently of each other. In addition, ControlLogix controllers also support a variety of communication protocols, such as RS-232-C (DF1/DH-485 protocol), DeviceNet, DH+, ControlNet, EtherNet/IP, etc., to achieve communication with other computers or other processors.

Overall, the 1756-L55 ControlLogix processor module is a high-performance, reliable and flexible industrial automation component that can meet a wide range of complex control needs.
