描述

1756-TBS6H 接線端子

Allen-Bradley 1756- tbs6h是一個用于1756個I/O模塊的可移動終端塊(RTB)。它是一個I/O模塊附件，必須單獨訂購。它為互連1756 I/O模塊和工業工廠布線提供了靈活性。它很容易插入I/O模塊的前部。

該1756-TBS6H可移動端子塊是一個36針彈簧夾與標準外殼(接線臂深度< 2.5 ?€-mm?€- ^2)。它的尺寸為5.51 x 4.41 x 5.71英寸。它重0.3磅。對于布線，使用0.33 – 2.1 ?€-mm?€- ^2 (22 – 14 AWG)實心或絞合銅線，額定90°C(194°F)或更高，規格為1.2毫米(3/64英寸)最大絕緣。在任何一個端子上，不要使用多個導體。

每個ControlLogix I/O模塊安裝在任何ControlLogix機箱中，并需要一個可移動的終端塊(RTB)來連接所有現場側接線。每個I/O模塊都有許多應用，從高速數字處理到過程控制。在ControlLogix架構中，使用生產者-消費者技術在相同或不同機箱中的多個控制器之間共享輸入和輸出狀態。1756-TBS6H RTB適用于清潔干燥的工業環境，工作溫度為0-60°C，工作沖擊為30g。

1756-TBS6H 接線端子

The Allen-Bradley 1756-TBS6H is a Removable Terminal Block (RTB) for 1756 I/O modules. It is an I/O module accessory and must be ordered separately. It provides flexibility in interconnecting 1756 I/O modules and industrial plant wiring. It is easily plugged into the front section of the I/O module.

The 1756-TBS6H removable terminal block is a 36-pin spring-clamp with standard housing (wiring arm depth < 2.5 ?€–mm?€—^2). It has dimensions of 5.51 x 4.41 x 5.71 in. and it weighs 0.3 pounds. For wiring, use 0.33 – 2.1 ?€–mm?€—^2 (22 – 14 AWG) solid or stranded copper wire, rated at 90 °C (194 °F) or greater with a gauge of 1.2 mm (3/64 in.) maximum insulation. On any single terminal, do not use multiple conductors.

Each ControlLogix I/O module mounts in any ControlLogix chassis and requires a removable terminal block (RTB) to connect all the field-side wiring. Each I/O module has many applications ranging from high-speed digital processing to process control. In ControlLogix architecture, input and output status is shared among multiple controllers in the same or different chassis using producer-consumer technology. The 1756-TBS6H RTB is intended for use in a clean and dry industrial environment with a 0-60 °C operating temperature and a 30g operating shock.
