描述

1762SC-IF8U? ? 8v, C，或TC，或4 RTD/Res(2,3或4線)

1762sc-IF8U是一個8輸入模塊，屬于Micrologix系列兼容使用。該模塊由Spectrum controls制造和設計。1762s-IF8U支持8個通道兼容電壓，電流，熱電偶輸入。如果配置為D輸入，最多可以配置我們的(4)通道。它可以承受60攝氏度的最高溫度和10到500赫茲的工作振動。它可以在最高海拔2000米的地方使用。如果海拔較高，驅動器必須降額。

1762s-IF8U和其他1762級聯模塊一樣，需要接地。這將有助于防止影響每個通道的電磁干擾。該模塊被設計安裝在DIN導軌或安裝板上。如果需要，必須通過其DIN導軌與模塊進行額外連接。在模塊和其他設備之間必須留出額外的空間，因?yàn)檫@將有助于它有更好的通風。在安裝1762s-IF8U時，應盡量縮短線纜的長度，以保持最大的精度。模塊應盡可能靠近輸入設備，以保證準確的操作。

1762sc-IF8U是MicroLogix可編程邏輯控制器第三方擴展模塊。該模塊由Allen-Bradley的合作伙伴Spectrum Controls公司制造。該模塊具有兼容電壓，電流和熱電偶輸入的八(8)個輸入通道和電阻溫度檢測器(RTD)的四(4)個通道。

該模塊支持多通道配置，例如八(8)通道以下電壓/電流/熱電偶配置，六(6)通道配置為電壓/電流/熱電偶和一(1)通道配置為RTD/電阻，四(4)通道配置為電壓/電流/熱電偶和兩(2)通道RTD/電阻，兩(2)通道電壓/電流/熱電偶和三(3)通道RTD/電阻和四(4)通道RTD/電阻。

兼容的熱電偶傳感器包括B型熱電偶、C型熱電偶、E型熱電偶、J型熱電偶、K型熱電偶、N型熱電偶、R型熱電偶、S型熱電偶、T型熱電偶。兼容的RTD傳感器有100 ?Pt嗎?0.385, 200 ?Pt嗎?0.385, 500 ?Pt嗎?0.385還是1000 ?Pt嗎?0.385, 100 ?Pt嗎?0.3916, 200 ?Pt嗎?0.3916,500 ?Pt嗎?0.3916, 1000 ?Pt嗎?0.3916, 10 ?銅?0.426, 100 ?倪?0.618, 120 ?倪?0.672, 604 ?鎳鐵嗎?0.518. 對于電阻輸入，兼容的信號包括0到150 ?，0到1000 ?從0到3000 ?電壓信號兼容±50mv、±100mv、0 ~ 5v、1 ~ 5v、±10v、0 ~ 10v。電流信號的兼容范圍為4 ~ 20ma和0 ~ 20ma。

輸入信號通過集成的模數轉換器轉換為數字值。轉換后的值可以保存為不同的數據格式，如工程單位×1、工程單位×10、按比例縮放的pid和原始/比例數據。每個通道有單獨的輸入濾波器4赫茲，17赫茲，62赫茲和470赫茲。

1762SC-IF8U? ? 8v, C，或TC，或4 RTD/Res(2,3或4線)

The 1762sc-IF8U is an 8-input module that belongs to is compatible for use with Micrologix series. This module is manufactured and designed by Spectrum controls. The 1762s-IF8U supports Eight (8) channels compatible for voltage, current, thermocouple inputs. If configured for D input, up to our (4) channels may be configured. It can withstand a maximum temperature of 60 degrees Celsius and operating vibrations of 10 to 500 Hertz. It can be used at a maximum altitude of 2000 meters. If the altitude is higher, the drive must be derated.

The 1762s-IF8U, similar to other 1762 expansion modules, requires proper connection to a grounding system. This will help to prevent electromagnetic interference affecting each channel. This module is designed to be mounted on a DIN rail or a mounting plate. If required, additional connections to the module must be made through its DIN rail. Additional space must be left between the module and other equipment because this will help it to have better ventilation. When installing the 1762s-IF8U, the cables must be left as short as possible, to maintain maximum accuracy. The module should be located as close as possible to the input devices in order to guarantee accurate operations.

The 1762sc-IF8U is a MicroLogix Programmable Logic Controller 3rd party expansion module. This module is manufactured by Spectrum Controls, an Allen-Bradley encompass partner company. This module features Eight (8) input channels compatible for Voltage, Current and Thermocouple input and Four (4) Channels for Resistance Temperature Detector (RTD).

This module supports multiple channel configurations such as Eight (8) channels following Voltage/Current/Thermocouple configuration, Six (6) channels configured as Voltage/Current/Thermocouple and One (1) channel configured for RTD/Resistance, Four (4) channels configured as Voltage/Current/Thermocouple and Two (2) channels RTD/Resistance, Two (2) channels Voltage/Current/Thermocouple and Three (3) channels RTD/Resistance and Four (4) channels RTD/Resistance.

Compatible Thermocouple sensors include B Type Thermocouple, C Type Thermocouple, E Type Thermocouple, J Type Thermocouple, K Type Thermocouple, N Type Thermocouple, R Type Thermocouple, S Type Thermocouple, T Type Thermocouple. Compatible RTD sensors are 100 ? Pt ? 0.385, 200 ? Pt ? 0.385, 500 ? Pt ? 0.385, 1000 ? Pt ? 0.385, 100 ? Pt ? 0.3916, 200 ? Pt ? 0.3916, 500 ? Pt ? 0.3916, 1000 ? Pt ? 0.3916, 10 ? Cu ? 0.426, 100 ? Ni ? 0.618, 120 ? Ni ? 0.672, 604 ? NiFe ? 0.518. For resistance inputs, compatible signals include 0 to 150 ?, 0 to 1000 ? and 0 to 3000 ?. For Voltage signals, compatible signals are ±50 mV, ±100 mV, 0 to 5 V, 1 to 5 V, ±10 V and 0 to 10 V. For Current signals, compatible values are 4 to 20 mA and 0 to 20 mA.

Input signals are converted to digital values via an integrated Analog to Digital converter. Converted values may save to different data formats such as Engineering units ×1, Engineering units ×10, Scaled-for-PID, and Raw/proportional data. Each channels has individual input filters 4 Hz, 17 Hz, 62 Hz and 470 Hz.
