描述

1783-CMS10DN 端口交換機

Allen-Bradley 1783-BMS10CA交換機是一種管理型以太網交換機，共有10個端口。其中8個端口為銅端口，另外2個端口為combo端口。8個銅端口支持通過RJ-45接口進行快速以太網通信。combo端口通過RJ-45接口或光纖SFP插槽支持快速以太網通信。1783-BMS10CA交換機屬于Stratix 5700系列以太網交換機。1783-BMS10CA開關上的報警繼電器在30伏直流時額定電流為1安培，在48伏直流時額定電流為0.5安培。1783-BMS10CA交換機最大功耗為17w。開關的典型功耗為24伏直流12.5瓦。1783-BMS10CA開關的額定功耗為17瓦。

1783-BMS10CA交換機支持多種SFP模塊，包括1783-SFP100FX、1783-SFP100LX、1783-SFP100EXC、1783-SFP100ZXC、1783-SFP100T、1783-SFP1GSX、1783-SFP1GLX、1783-SFP1GEXE、1783-SFP1GZX和1783-SFP1GTE模塊。1783-BMS10CA交換機支持1784-SD1內存卡。交換機符合的行業標準包括IEEE 1613和IEC 61850-3標準。1783-BMS10CA開關的工作溫度范圍為-40至140華氏度。非工作溫度范圍從-40到185華氏度。交換機的外殼是打開的，尺寸為5.1 x 3.6 x 4.59英寸。為了確保開關周圍的環境溫度保持在建議的范圍內，Allen-Bradley建議在開關周圍保持至少2英寸的空間。直流電源線推薦使用20 ~ 18awg的銅線。

1783-CMS10DN 端口交換機

The Allen-Bradley 1783-BMS10CA switch is a managed Ethernet switch with a total of 10 ports. Eight ports are copper ports and the other two are combo ports. Eight copper ports support fast Ethernet communication via the RJ-45 port. combo port Supports fast Ethernet communication through an RJ-45 port or an optical fiber SFP slot. The 1783-BMS10CA switch is a Stratix 5700 series Ethernet switch. The alarm relay on the 1783-BMS10CA switch is rated for 1 amp at 30 V DC and 0.5 amp at 48 V DC. The maximum power consumption of the 1783-BMS10CA switch is 17w. The typical power consumption of the switch is 24 volts DC 12.5 watts. The 1783-BMS10CA switch is rated for 17 watts.

1783-BMS10CA switch supports multiple SFP modules, Including 1783-SFP100FX, 1783-SFP100LX, 1783-SFP100EXC, 1783-SFP100ZXC, 1783-SFP100T, 1783-SFP1GSX, 1783-SFP1GLX, 1783-SFP1GEXE, 1783-SF P1GZX and 1783-SFP1GTE modules. The 1783-BMS10CA switch supports 1784-SD1 memory cards. Industry standards for switch compliance include IEEE 1613 and IEC 61850-3 standards. The 1783-BMS10CA switch operates in a temperature range of -40 to 140 degrees Fahrenheit. Non-operating temperatures range from -40 to 185 degrees Fahrenheit. The switch’s housing is open and measures 5.1 x 3.6 x 4.59 inches. To ensure that the ambient temperature around the switch stays within the recommended range, Allen-Bradley recommends maintaining at least 2 inches of space around the switch. 20 to 18awg copper cables are recommended for DC power cables.
