描述

20F1ANC367JAONNNNN 帶預充電的交流輸入，無直流端子

753交流驅動，風冷，開式，400V交流3 PH, 367安，200kW ND, 160kW HD，交流In Prchg Prchg無直流項，框架7，濾波CM跳線安裝，DB晶體管，空白(無HIM)，紙箱和文件。

艾倫-布拉德利20F1ANC367JAONNNNN驅動器是艾倫-布拉德利/羅克韋爾自動化公司的變頻驅動器。該驅動器屬于Allen-Bradley的PowerFlex 753系列交流驅動器。該驅動器的額定電流為265安培。在正常負載條件下，驅動器的額定電壓為交流400伏和直流540伏。該驅動器的幀大小從6到8或從2到7。框架尺寸6至8的外殼帶有內置預充電的交流輸入端子，但沒有直流端子?？蚣艹叽?至7的外殼帶有IP 20/IP 00額定NEMA UL開放式外殼。IP等級表示該驅動器不防水。20F1ANC367JAONNNNN驅動器的額定輸出功率為300馬力。驅動器安裝了跳線作為默認的CM帽連接。在這個驅動器變體中既沒有內部電阻也沒有內部晶體管。

20F1ANC367JAONNNNN驅動器配備了嵌入式輸入/輸出模塊。該驅動器有一個微處理器控制的散熱器熱敏電阻，當它檢測到驅動器內部溫度過高時，就會發出警報并跳閘。驅動器是風冷的，在最近的通風源和驅動器的散熱器之間不應存在障礙物。足夠的垂直間隙應該存在周圍的驅動器安裝現場。20F1ANC367JAONNNNN驅動器是一個三相器件，配備CM跳線。在此驅動器變體中不存在人機接口模塊。對于轉矩調節，驅動器配備了伏特每赫茲控制，力技術矢量控制和無傳感器矢量控制算法。這三種算法都有助于驅動器滿足不同的應用需求。

20F1ANC367JAONNNNN 帶預充電的交流輸入，無直流端子

753 AC Drive, Air Cooled, Open Type, 400V AC 3 PH, 367 Amps, 200kW ND, 160kW HD, AC In Prchg Prchg No DC Term, Frame 7, Filtered CM Jumper Installed, DB Transistor, Blank (No HIM), Carton and Documents.

The Allen-Bradley 20F1ANC367JAONNNNN drive is a variable frequency drive from Allen-Bradley/Rockwell Automation. The drive belongs to the PowerFlex 753 series of AC drives from Allen-Bradley. The drive has a current rating of 265 Amps. The voltage rating of the drive is 400 Volts AC and 540 Volts DC under normal loading conditions. The drive is available in frame sizes from 6 to 8 or from 2 to 7. The enclosure for the frame sizes 6 to 8 comes with an AC input terminal with built-in precharge but it has no DC terminals. The enclosure for the frame sizes 2 to 7 comes with an IP 20/IP 00 rated NEMA UL open enclosure. The IP rating indicates that the drive is not waterproof. The 20F1ANC367JAONNNNN drive has a 300 Horsepower output rating. The drive is installed with a jumper as the default CM cap connection. Neither an internal resistor or an internal transistor is present in this drive variant.

The 20F1ANC367JAONNNNN drive is equipped with an embedded input/output module. The drive has a microprocessor-controlled heatsink thermistor which alerts and trips the drive whenever it detects over-temperature inside the drive. The drive is air-cooled and no obstruction should present between the nearest ventilation source and the heatsink of the drive. Enough vertical clearance should be present all around the drive on the installation site. The 20F1ANC367JAONNNNN drive is a 3-phase device and it is equipped with a CM jumper. No human-machine interface module is present in this drive variant. For torque regulation, the drive is equipped with Volts per Hertz control, vector control with Force technology, and the Sensorless vector control algorithm. All of these 3 algorithms help the drive to meet different application demands.
