描述

2711PC-T10C4D8? ?PanelView Plus 6 600 緊湊型終端

2711PC-T10C4D8 PanelView Plus 6是Allen-Bradley的緊湊型圖形終端。憑借其緊湊的設計和固定的配置，它是一個流行的艾倫-布拉德利HMI(人機界面)為CompactLogix控制器。2711PC-T10C4D8具有一個RS-232串口、一個以太網端口和2個支持串行和以太網通信的USB端口。2711PC-T10C4D8終端配備10.4英寸彩色有源矩陣TFT，帶有電阻式觸摸輸入。顯示器分辨率為640 x 480像素，具有18位彩色圖形。它重5.6磅，尺寸為9.77 x 12.97 x 2.18英寸。2711PC-T10C4D8具有512 MB非易失性閃存和512 MB RAM。它還支持用于外部存儲的安全數字(SD)卡。

2711PC-T10C4D8端子的直流輸入電壓為18 ~ 30v DC(標稱24v DC)，最大功耗為70w。對于安裝，它可以面板安裝NEMA/UL類型12,13,4x和IP54或IP65額定外殼。通過ActiveX控件、備份恢復和遠程連接等附加功能，它為用戶提供了極大的靈活性。各種外部設備，如鼠標或鍵盤可以連接到它。2711PC-T10C4D8是Allen-Bradley PanelView Plus 6緊湊型終端。2711PC-T10C4D8 PanelView Plus 6緊湊型終端具有8.3 x 6.2英寸彩色顯示屏和觸摸屏輸入。

這個人機界面通過彩色編碼顯示和動畫支持高信息量圖形的設計。它可以配置為遵循國際顏色標準，以指示設備，設備和過程或機器的運行狀態。

該人機界面由24VDC輸入電源供電。建議采用外部保護，避免損壞硬件。該操作終端配備了一個嵌入式512 MB隨機存取存儲器(RAM)和512 MB非易失性存儲器(約為1mb)。79 MB可用用戶內存)。

2711PC-T10C4D8? ?PanelView Plus 6 600 緊湊型終端

The 2711PC-T10C4D8 PanelView Plus 6 is a compact graphics terminal by Allen-Bradley. With its compact design and fixed configuration, it is a popular Allen-Bradley HMI (human-machine interface) for CompactLogix controllers. The 2711PC-T10C4D8 has an RS-232 serial port, an Ethernet port, and 2 USB ports that support serial and Ethernet communications. The 2711PC-T10C4D8 terminal comes with a 10.4-inch color active-matrix TFT with a resistive touch input. The display resolution is 640 x 480 pixels and it has 18-bit color graphics. It weighs 5.6 pounds and measures 9.77 x 12.97 x 2.18 inches. The 2711PC-T10C4D8 has 512 MB non-volatile flash memory and 512 MB of RAM. It also supports a Secure Digital (SD) card for external storage.

The 2711PC-T10C4D8 terminal requires a DC input voltage of 18 to 30 Volts DC (24 Volts DC nominal) and it has a maximum power consumption of 70 W. For installation, it can be panel-mounted with NEMA/UL Type 12, 13, 4X, and IP54 or IP65 rated enclosures. With additional features such as ActiveX controls, backup restore, and remote connectivity, it provides great user flexibility. Various external devices such as a mouse or keyboard can be connected to it. The 2711PC-T10C4D8 is an Allen-Bradley PanelView Plus 6 Compact Terminal. The 2711PC-T10C4D8 PanelView Plus 6 Compact Terminal has an 8.3 x 6.2 inches color display with touchscreen input.

This HMI support design of highly informative graphics through color coded display and animation. It may be configured to follow international color standards to indicate operational status of a device, equipment and a process or machine.

This HMI is powered by an 24VDC input supply. External protection is recommended to prevent damage to the hardware. This operator terminal comes with an embedded 512 MB Random Access Memory (RAM) and 512 MB nonvolatile memory (approx. 79 MB free user memory).
