描述

31C075-503-4-00 動態調整模型數據庫結構以滿足實際系統需求

PLC主要應用的領域　

1．開關量邏輯控制

　　取代傳統的繼電器電路，實現邏輯控制、順序控制，既可用于單臺設備的控制，也可用于多機群控及自動化流水線。如注塑機、印刷機、訂書機械、組合機床、磨床、包裝生產線、電鍍流水線等。

2．工業過程控制

　　在工業生產過程當中，存在一些如溫度、壓力、流量、液位和速度等連續變化的量（即模擬量），PLC采用相應的A/D和D/A轉換模塊及各種各樣的控制算法程序來處理模擬量，完成閉環控制。PID調節是一般閉環控制系統中用得較多的一種調節方法。過程控制在冶金、化工、熱處理、鍋爐控制等場合有非常廣泛的應用。

3．運動控制

　　PLC可以用于圓周運動或直線運動的控制。一般使用專用的運動控制模塊，如可驅動步進電機或伺服電機的單軸或多軸位置控制模塊，廣泛用于各種機械、機床、機器人、電梯等場合。

4．?dāng)?shù)據處理

　　PLC具有數學運算（含矩陣運算、函數運算、邏輯運算）、數據傳送、數據轉換、排序、查表、位操作等功能，可以完成數據的采集、分析及處理。數據處理一般用于如造紙、冶金、食品工業中的一些大型控制系統。

5．通信及聯網

PLC通信含PLC間的通信及PLC與其它智能設備間的通信。隨著工廠自動化網絡的發展，現在的PLC都具有通信接口，通信非常方便。

◆測試系統概述： ?
本系統主要針對各種工業、民用設備和系統的部件 （包括控制器、傳感器和執行器等）進行功能和性能 測試，采用系統仿真技術實現設備和系統中與被測部件 相關的其他部件的仿真與模擬功能，從而實現被測部件的運行環境仿真測試。
運行環境仿真系統的開發首先集中于仿真模型，精確建立一個針對機電部件和系統的動態案例仿真模型庫。
這個模型庫有三個優點：
·基于案例推理技術的仿真模型分類結構：它可以 動態調整模型數據庫結構以滿足實際系統需求。
·測試仿真模型和真實系統匹配度的功能
·系統辯識工具：可以從實際的實驗結果中提取精 確模型，并重構動態模型庫。
這些優點可以有效地解決以前靜態模型庫帶給仿真實驗的問題。動態仿真模型庫具有動態和自適應能力， 可以滿足更廣泛的需求。運行環境仿真系統以虛擬儀器 技術為基礎的硬件在環測試系統，這使仿真變得更加容易。

31C075-503-4-00 動態調整模型數據庫結構以滿足實際系統需求

The main application areas of PLC

1. Switch quantity logic control

Instead of the traditional relay circuit, it can realize logic control and sequence control, which can be used for the control of a single device, and can also be used for multi-machine group control and automatic pipeline. Such as injection molding machines, printing presses, stapler machines, combined machine tools, grinding machines, packaging production lines, electroplating lines, etc.

2. Industrial process control

In the industrial production process, there are some continuous changes such as temperature, pressure, flow, liquid level and speed (that is, the analog amount), PLC uses the corresponding A/D and D/A conversion modules and a variety of control algorithms to deal with the analog amount, complete closed-loop control. PID regulation is a kind of regulation method used in general closed-loop control system. Process control is widely used in metallurgy, chemical industry, heat treatment, boiler control and so on.

3. Motion control

PLC can be used to control circular or linear motion. Generally use special motion control modules, such as single-axis or multi-axis position control modules that can drive stepper motors or servo motors, widely used in various machinery, machine tools, robots, elevators and other occasions.

4. Data processing

PLC has mathematical operations (including matrix operations, function operations, logical operations), data transmission, data conversion, sorting, table lookup, bit operation and other functions, can complete the data collection, analysis and processing. Data processing is generally used in some large control systems in the paper, metallurgy, and food industries.

5. Communication and networking

PLC communication includes communication between PLC and communication between PLC and other intelligent devices. With the development of factory automation network, PLC now has a communication interface, communication is very convenient.

◆ Test system overview:
The system mainly tests the functions and performance of various industrial and civil equipment and system components (including controllers, sensors and actuators, etc.), and adopts system simulation technology to realize the simulation and simulation functions of other components related to the components under test in the equipment and system, so as to realize the simulation test of the operating environment of the components under test.
The development of the operating environment simulation system first focuses on the simulation model, and precisely establishes a dynamic case simulation model base for electromechanical components and systems.
This model library has three advantages:
Simulation model classification structure based on case-based reasoning technology: it can dynamically adjust the model database structure to meet the actual system requirements.
· Function of testing the match between simulation model and real system
· System identification tools: accurate models can be extracted from actual experimental results and dynamic model libraries can be reconstructed.
These advantages can effectively solve the problems brought by static model library to simulation experiments. The dynamic simulation model library has dynamic and adaptive capabilities to meet a wider range of needs. The operating environment simulation system is a hardware-in-the-loop test system based on virtual instrument technology, which makes the simulation easier.
