描述

330105-02-10-02-00 測振探頭

本特利Bently Nevada 330105-02-10-02-00 振動變送器集成式前置器傳感器無需外部裝置非隔離 PROX OUT 和 COM 端子加上同軸連接器非交互零位和跨度電位器測試輸入引腳，本特利Bently Nevada 330105-02-10-02-00振動變送器用于快速驗證環路信號輸出不正常/信號故障電路可防止高輸出或誤報封裝結構適用于高濕度環境(高達 100% 冷凝)。本特利Bently Nevada 330105-02-10-02-00 振動變送器主要用于離心空氣壓縮機或小型泵、電機或風扇的原始設備制造商 (OEM)，他們喜歡提供簡單的 4 到20 mA 比例振動信號作為其機械控制系統的輸入。

以上就是關于“本特利Bently Nevada 330105-02-10-02-00 振動變送器的特征”的相關介紹。本特利Bently Nevada 公司檢測控制技術的重點業務涵蓋了各行各業和眾多應用，包括無損檢測(NDT)、傳感、資產狀態監測、控制和儀表和輻射測量。我們正不斷建立最佳實踐并探索未來的解決方案，這一切的努力都是為了保證我們的客戶享有質量、安全、服務和生產率。本特利Bently Nevada傳感器通常安裝于機器內部或表面，用于測量振動、位移、轉速、壓力、扭矩及能量等。本特利內華達提供多種傳感器，均可滿足工業環境的使用要求，部分傳感器在采取本質安全柵、電磁絕緣等方法后，可安裝于危險地區。

330105-02-10-02-00鍵相器模塊

330105-02-10-02-00?改進的鍵相器模塊是一個半高度，2?通道模塊，用來為3500?框架中的監視器模塊提供鍵相位信號。此模塊接收來自電渦流傳感器或電磁式傳感器的輸入信號，并轉換此信號為數字鍵相位信號，該數字信號可指示何時轉軸上的鍵相位標記通過鍵相位探頭。每個鍵相模塊有2個輸入通道，330105-02-10-02-00?機械保護系統可安裝2個鍵相器模塊，接收4個鍵相位信號。

注:??鍵相位信號是來自旋轉軸或齒輪的每轉一次或每轉多次的脈沖信號，提供精確的時間測量。允許330105-02-10-02-00?監測器模塊和外部故障診斷設備用來測量諸如1X?幅值和相位等向量參數。

每個鍵相器模塊可接收2?個來自渦流傳感器或電磁傳感器的信號。輸入信號范圍為-0.8V到-21.0V(非絕緣I/O?模塊)和+5V到-11V(絕緣I/O?模塊)。模塊內可限幅，使信號不得超過此范圍。無源電磁傳感器要求軸轉速大于200rpm(3.3Hz)。在框架前面板上，通過同軸接頭，有2?個緩沖鍵相位輸出信號。2?個緩沖鍵相位輸出同樣可在框架背面，通過歐式接頭得到。前面板發光二極管?OK?指示燈:?可指示在鍵相器模塊內檢測到一個故障。

330105-02-10-02-00 測振探頭

Bentley Bently Nevada 330105-02-10-02-00 Vibration transmitter Integrated pre-sensor without external device Non-isolated PROX OUT and COM terminals plus coaxial connectors Non-interactive zero and span potentiometer test input pins, Bentley Bently Nevada 330105-02-10-02-00 Vibration transmitter for rapid verification of loop signal output anomalies/signal failures The circuit prevents high output or false positives The package structure is suitable for high humidity environments (up to 100% condensation). Bentley Bently Nevada 330105-02-10-02-00 Vibration transmitters are primarily used by original equipment manufacturers (Oems) in centrifugal air compressors or small pumps, motors or fans who prefer to provide a simple 4 to 20 mA proportional vibration signal as input to their mechanical control systems.

The above is about the “Bentley Bently Nevada 330105-02-10-02-00 vibration transmitter characteristics”. Bentley Bently Nevada’s focus on inspection and control technologies spans a wide range of industries and applications, including nondestructive testing (NDT), sensing, asset condition monitoring, control and instrumentation, and radiation measurement. We are constantly establishing best practices and exploring future solutions, all in an effort to ensure quality, safety, service and productivity for our customers. Bentley Bently Nevada sensors are typically installed inside or on the surface of machines to measure vibration, displacement, speed, pressure, torque and energy. Bentley Nevada offers a wide range of sensors that meet the requirements of industrial environments, and some sensors can be installed in hazardous areas with intrinsic safety barriers, electromagnetic insulation, and other methods.

330105-02-10-02-00 Key phase module

330105-02-10-02-00 The improved key phase module is a half-height, 2-channel module designed to provide key phase signals to the monitor module in the 3500 frame. This module receives an input signal from an eddy current sensor or an electromagnetic sensor and converts this signal into a digital key phase signal that indicates when the key phase mark on the rotating shaft passes through the key phase probe. Each key phase module has 2 input channels, 330105-02-10-02-00 mechanical protection system can install 2 key phase modules, receive 4 key phase signals.

Note: The key phase signal is a pulse signal from the rotating shaft or gear once or multiple times per revolution, providing accurate time measurement. The 330105-02-10-02-00 monitor module and external fault diagnosis equipment are allowed to measure vector parameters such as 1X amplitude and phase.

Each key phaser module can receive 2 signals from eddy current sensors or electromagnetic sensors. The input signals range from -0.8V to -21.0V(uninsulated I/O modules) and +5V to -11V(insulated I/O modules). The module can be clipped so that the signal does not exceed this range. The shaft speed of a passive electromagnetic sensor must be greater than 200rpm(3.3Hz). On the front panel of the frame, through the coaxial connector, there are 2 buffer keys phase output signals. The 2 buffer key phase outputs are also available on the back of the frame via European joint. Front panel LED OK indicator: indicates that a fault has been detected in the key phaser module.
