3301050-02-12-15-02-05 接近傳感器系統
1. 1米系統不使用延伸電纜。
2. Proximitor傳感器默認由工廠提供，校準為AISI 4140鋼。可根據要求校準其他目標材料。
3. 參考Bently Nevada*應用說明，當考慮使用該傳感器系統進行轉速表或超速測量時，使用渦流接近探頭進行超速保護應用時的注意事項。
4. 8mm組件在電氣和物理上可與非xl 3300 5命令8mm組件互換。雖然3300 XL Proximitor傳感器的包裝不同于它的前身，但它的設計適合于相同的4孔安裝模式，當與4孔安裝基礎一起使用時，并將適用于相同的安裝空間規格(當最小允許彎曲半徑被觀察到)。
5. 混合XL和非XL 3300系列5毫米和8毫米系統組件限制了系統性能的規格，非XL 3300 5毫米和8毫米傳感器系統。
6. 3300系列5毫米探頭(請參閱規格和訂購信息p/n 141605-01)使用更小的物理包裝，但與8毫米探頭相比，不會減少側面視圖間隙或尖端到尖端間距要求。當物理(非電氣)限制不允許使用8毫米探頭時使用。當您的應用需要窄側視圖探頭時，請使用3300 NSv*接近傳感器系統(請參閱規格和訂購信息p/n 147385-01)。
7. 8毫米探頭提供了一個更厚的封裝探頭線圈在模壓PPS塑料探頭尖端。這導致了一個更堅固的探頭。更大直徑的探頭體也提供了一個更強，更堅固的情況下。我們建議您盡可能使用8毫米探頭，以提供最佳的健壯性，防止身體濫用。
8. 每根3301050-02-12-15-02-05加長電纜包括硅膠膠帶，可以代替連接器保護器使用。我們不建議硅膠膠帶的應用，將探頭到延長電纜連接到渦輪油。
3301050-02-12-15-02-05 接近傳感器系統
1. 1-metre systems do not use an extension cable.
2. Proximitor sensors are supplied by default from thefactory calibrated to AISI 4140 steel. Calibration toother target materials is available upon request.
3. Consult Bently Nevada* Applications Note,Considerations when using Eddy Current ProximityProbes for Overspeed Protection Applications, whenconsidering this transducer system for tachometer oroverspeed measurements.
4. 3301050-02-12-15-02-05 8 mm components are both electrically andphysically interchangeable with non-XL 3300 5 mmand 8 mm components. Although the packaging ofthe 3300 XL Proximitor Sensor differs from itspredecessor, its design fits in the same 4-holemounting pattern when used with the 4-holemounting base, and will fit within the same mountingspace specifications (when minimum permissiblecable bend radius is observed).
5. Mixing XL and non-XL 3300-series 5 mm and 8 mmsystem components limits system performance to thespecifications for the non-XL 3300 5 mm and 8 mmTransducer System.
6. The 3300-series 5 mm probe (refer to Specificationsand Ordering Information p/n 141605-01) usessmaller physical packaging, but does not reduce theside view clearances or tip-to-tip spacingrequirements as compared to an 8 mm probe. It isused when physical (not electrical) constraintspreclude the use of an 8 mm probe. When yourapplication requires narrow side view probes, use the3300 NSv* Proximity Transducer System (refer toSpecifications and Ordering Information p/n 147385-01).
7. 8 mm probes provide a thicker encapsulation of theprobe coil in the molded PPS plastic probe tip. Thisresults in a more rugged probe. The larger diameterof the probe body also provides a stronger, morerobust case. We recommend that you use 8 mmprobes when possible to provide optimal robustnessagainst physical abuse.
8. Each 3301050-02-12-15-02-05 extension cable includes silicone tapethat you can use instead of connector protectors. Wedo not recommend silicone tape for applications thatwill expose the probe-to-extension cable connectionto turbine oil.
