330701-00-30-10-02-00 前置器探頭
產品描述
部分沒有。: 330701-00-30-10-02-00
制造商:內華達州本特利
產品類型:前置器探頭
系列:本利內華達3300
330701-00-30-10-02-00是Bently Nevada公司3300系列的近距離探頭。它是3300 XL 11毫米接近傳感器系統的附件。探頭，延長線和Proximitor傳感器包含在3300 XL 11毫米接近傳感器系統中。
探頭的工作溫度范圍為-52℃~ +177℃，適用于操作和存儲。3300 XL探頭用于密封探頭尖端和套管之間的壓差。Viton o形環作為探針的密封材料。在裝運前，探頭不進行壓力檢查。如果您需要為您的應用進行壓力密封測試，請聯系我們的定制設計部門。所有傳感器系統組件使用鍍金黃銅ClickLoc連接器。ClickLoc連接確保連接安全，防止連接松動。
獲得專利的TipLoc成型技術在探針尖端和探針體之間建立了牢固的附著。探頭電纜使用我們獨特的CableLoc設計牢固地連接到探頭尖端，其拉力為330 N。
FluidLoc電纜選項可用于3300 XL探頭和延長電纜。此選項可防止油和其他液體通過電纜內部泄漏出機器。它還可以保護連接器在潮濕或潮濕的環境中不受潮。
建議所有安裝都使用連接器保護器，有助于保護環境。
330130-085-01-05是內華達州本特利制造的3300 XL標準延長電纜，用于近距離傳感器系統。接近傳感器來自工廠，具有AISI 4140鋼的標準校準。它可以按需校準到其他目標材料。你可以咨詢Bently Nevada Applications。當評估用于轉速表或超速測量的傳感器系統時，使用渦流接近探頭進行超速保護應用時，請注意要考慮的因素。從物理和技術上講，非XL 3300 5和8毫米組件可以替換為3300 XL 8毫米組件。即使3300 XL Proximitor?傳感器的包裝與其前身不同，當與相同的安裝底座的4孔安裝模式一起使用時，它仍然被設計成適合相同的4孔安裝模式，并將堅持相同的安裝空間要求。
當XL和非XL 3300系列5和8毫米系統組件組合時，系統性能僅限于非XL 3300 5和8毫米傳感器系統標準。
3300系列5毫米探頭(見規格和訂購信息p/n 141605-01)具有比8毫米探頭更小的物理足跡，但它不能用于減少側視圖間隙或尖端到尖端間距。
當物理限制(而非電氣限制)禁止使用8mm探頭時，使用這種方法。當需要窄側視圖探頭時，使用3300 NSvTM接近傳感器系統。
在模壓PPS塑料探頭尖端的探頭線圈的更厚的封裝由8毫米探頭提供。因此，探針變得更加健壯。
探頭體的直徑增加也提供了一個更堅固，更耐用的外殼。為了最好地抵抗身體虐待，本特利內華達建議在可行的地方使用8毫米的探針。
330701-00-30-10-02-00 前置器探頭
Products Description
Part No. : 330701-00-30-10-02-00
Manufacturer: Bently Nevada
Product Type: Proximitor Probe
Series: Bently Nevada 3300
330701-00-30-10-02-00 is a proximity probe produced by Bently Nevada in the 3300 series.? It is an accessory for the 3300 XL 11 mm Proximity Transducer System. The probe, extension cable, and Proximitor Sensor are included in the 3300 XL 11 mm Proximity Transducer System.
The temperature Range of the Probe is -52°C to +177°C for operation and storage. The 3300 XL probes are intended to seal differential pressures between the probe tip and the casing. A Viton O-ring serves as the probe’s sealing material. Prior to shipment, probes are not pressure checked. If you need a pressure seal test for your application, please contact our custom design department. All transducer system components use gold-plated brass ClickLoc connectors. ClickLoc connections secure the connection, preventing it from getting loose.
The TipLoc molding technology, which is patented, creates a strong attachment between the probe tip and the probe body. The probe cable is firmly linked to the probe tip using our unique CableLoc design, which has a pull strength of 330 N.
FluidLoc cable options are available for 3300 XL Probes and Extension Cables. This option prevents oil and other liquids from leaking out of the machine via the interior of the cable. It also protects the connectors from moisture in a humid or moist environment.
Connector protectors are suggested for all installations and help to safeguard the environment.
330130-085-01-05 is a?3300 XL Standard Extension Cable?manufactured by Bently Nevada and used in proximity transducer system. Proximity Sensors come from the factory with a standard calibration to AISI 4140 steel. It is possible to calibrate on-demand to additional target materials. You might consult Bently Nevada Applications. Take note of the factors to take into account when using eddy current proximity probes for Overspeed protection applications when assessing this transducer system for tachometer or Overspeed measurements. Physically and technologically, the non-XL 3300 5 and 8 mm components can be swapped out for the 3300 XL 8 mm components. Even if the packaging of the 3300 XL Proximitor? Sensor differs from that of its predecessor, it is still designed to fit in the same 4-hole mounting pattern when used with the same mounting base’s 4-hole mounting pattern and will adhere to the same mounting space requirements.
System performance is restricted to the non-XL 3300 5 and 8 mm Transducer System standards when XL and non-XL 3300 series 5 and 8 mm system components are combined.
The 3300-series 5 mm probe (see to Specifications and Ordering Information p/n 141605-01) has a smaller physical footprint than an 8 mm probe, but it cannot be used with reduced side view clearances or tip-to-tip spacing.
When the use of an 8 mm probe is prohibited by physical—not electrical—constraints, this method is used. Use the 3300 NSvTM Proximity Transducer System when narrow side view probes are needed.
A thicker encapsulation of the probe coil in the molded PPS plastic probe tip is offered by 8 mm probes. As a result, the probe becomes more robust.
The probe body’s increased diameter also offers a stronger, more durable casing. For the best robustness against physical abuse, Bently Nevada advises using 8 mm probes wherever it is practical.
