3500-25-149369-01 用于向3500機架中的監視器模塊提供Keyphasor信號
3500-25-149369-01是一種半高、雙通道模塊，用于向3500機架中的監視器模塊提供Keyphasor信號。該模塊接收來自近接探頭或磁性拾音器的輸入信號，并將這些信號轉換為數字Keyphasor信號，以指示軸上的Keyphasor標記何時與Keyphasor傳感器相一致。這種模塊的設計使得它能在擴展的鍵相信號處理能力方面超越以前的設計，同時保持與現有Keyphasor模塊的完全向下兼容性。
在3500機械保護系統中，最多可接受四個Keyphasor信號以實現正常配置，而在配對配置下最多可接受八個Keyphasor信號。鍵相位信號是來自旋轉軸或齒輪的每轉一次或每轉多次的脈沖信號，它提供精確的時間測量，并允許3500監測器模塊和外部故障診斷設備測量諸如1X幅值和相位等向量參數。
3500-25-149369-01還具有緩沖的傳感器輸出功能，可以通過同軸接頭或歐式接頭獲得。此外，模塊內還有發光二極管（OK指示燈）可以指示在鍵相器模塊內檢測到一個故障，以及一個通信指示燈，當鍵相器模塊與框架接口模塊（RIM）進行通訊時會發出指示。
3500-25-149369-01 用于向3500機架中的監視器模塊提供Keyphasor信號
The 3500-25-149369-01 is a half-height, dual-channel module that provides Keyphasor signals to monitor modules in the 3500 rack. The module receives input signals from proximity probes or magnetic pickups and converts these signals into digital Keyphasor signals to indicate when the Keyphasor mark on the shaft is aligned with the Keyphasor sensor. The design of this module enables it to surpass previous designs in terms of extended key signal processing power while maintaining full backward compatibility with existing Keyphasor modules.
In the 3500 mechanical protection system, up to four Keyphasor signals can be accepted for normal configuration, and up to eight Keyphasor signals can be accepted in the paired configuration. The key phase signal is a pulse signal from the rotating shaft or gear once or many times per revolution, which provides accurate time measurement and allows 3500 monitor modules and external fault diagnosis equipment to measure vector parameters such as 1X amplitude and phase.
The 3500-25-149369-01 also features a buffered sensor output, which can be obtained via a coaxial or European connector. In addition, there is a light-emitting diode (OK indicator) within the module to indicate that a fault has been detected within the key phaser module and a communication indicator to indicate when the key phaser module is communicating with the Frame Interface module (RIM).
