描述

350045 是一個4通道監視器

是一個4通道監視器， 接授來自接近傳感器,旋轉位置傳感器(RPT), DC線性變 量差動變壓器(DC LVDT),交流線性可變差動變壓器(交流LVDTs)和旋轉電位計。注:要進行的測量類型和相關的傳感器輸入決定需要輸入/輸出(/O0)模塊。參見表1以及圖1和圖2。它調節這些輸入，并將調節后的信號與用戶可編程報警進行比較。3500組態軟件可以對每個進行編程3500/45的通道執行以下任何功能:軸向(推力)位置差異膨脹標準單斜坡差異膨脹非標準單斜坡差異膨脹雙斜坡差異膨脹互補差異膨脹案例擴展位置注:監控通道成對編程，最多可執行其中兩項功能一次。通道1和2可以執行一種功能，而通道3和4執行另- -種功能(或同)功能。但是,只有通道和3和4可以執行案例擴展。3500/45監視器的主要目的是提供: 1.通過持續比較監控參數來保護機器根據配置的報警設定值驅動報警。2.操作和維護的基本機器信息人事。根據配置，每個通道通常會調節其輸入信號轉換成稱為”比例值”的各種參數。警報設定點可以是為每個主動比例值和危險設定值配置的可以是針對任意兩個有效比例值進行配置。

需要注意的是，對于具體的傳輸模塊，其性能、特性和使用方法可能會根據具體的產品和應用而有所不同。因此，在使用傳輸模塊時，最好參考具體產品的技術規格和用戶手冊，以獲得最準確和可靠的信息。

350045 是一個4通道監視器

It is a 4-channel monitor with connections from proximity sensors, rotary position sensors (RPT), DC linear variable differential transformers (DC LVDT), AC linear Variable differential transformers (AC LVDTs) and rotary potentiometers. Note: The type of measurement to be made and related sensor input decisions require an input/output (/O0) module. See Table 1 and Figures 1 and 2. It adjusts these inputs and compares the adjusted signal with a user programmable alarm. The 3500 configuration software can perform any of the following functions on each channel programmed 3500/45: Axial (thrust) position differential inflation Standard single slope Differential inflation Non-standard single slope differential inflation Dual slope Differential inflation Complementary Differential inflation Case Extended Position Note: The monitoring channels are programmed in pairs to perform up to two of these functions at once. Channels 1 and 2 May perform one function, while channels 3 and 4 perform another (or the same) function. However, only channels and 3 and 4 can perform case extensions. The main purpose of the 3500/45 monitor is to provide: 1. Protect the machine by continuously comparing monitoring parameters to drive alarms according to configured alarm Settings. 2. Operation and maintenance of basic machine information personnel. Depending on the configuration, each channel typically adjusts the conversion of its input signal to various parameters called “proportional values”. The alert set point can be configured for each active scale value and the danger set value and it can be configured for any two effective scale values.

It should be noted that for specific transmission modules, their performance, characteristics and usage methods may vary depending on the specific product and application. Therefore, when using transmission modules, it is best to refer to the technical specifications and user manuals of specific products to obtain the most accurate and reliable information.
