描述

350070M 脈沖/速度監視器模塊

3500/70M?是本特利（Bently Nevada）3500系列機械保護系統中的一個關鍵組件，通常用作往復式壓縮機解決方案包的一部分，用于監測壓縮機曲軸箱和橫梁的振動情況。

這款模塊是一個4通道監測器，可以接受來自地震傳感器的輸入信號，然后對這些信號進行調理以獲取各種振動測量值。調理后的信號會與用戶可編程的警報閾值進行比較，一旦振動超過預設的安全范圍，模塊就會觸發警報，從而及時通知操作人員采取必要的措施。

每個通道在3500框架配置軟件的幫助下，都可以被編程以執行多種功能，包括脈沖加速、往復加速度、往復速度等。這些功能的成對編程確保了在一次配置中，每個通道最多可以執行其中兩項功能。

此外，3500/70M的主要目標是提供持續的機械保護，通過比較監測的機械狀態與預設的警報設定點，以及提供操作和維護的基本機器信息，確保設備的安全和穩定運行。

總的來說，3500/70M是一個功能強大且靈活的監測模塊，能夠滿足各種往復式壓縮機振動監測的需求，為工業設備的安全運行提供有力的保障。然而，為了確保其最佳性能和長期穩定性，建議用戶遵循制造商的安裝指南和操作手冊進行正確的安裝、配置和維護。

350070M 脈沖/速度監視器模塊

The 3500/70M is a key component in Bently Nevada’s 3500 series of mechanical protection systems, commonly used as part of the reciprocating compressor solution package to monitor the vibration of the compressor crankcase and beam.

The module is a 4-channel monitor that accepts input signals from seismic sensors and then adjusts these signals to obtain various vibration measurements. The conditioned signal is compared to a user-programmable alarm threshold, and once the vibration exceeds the preset safety range, the module triggers an alarm, thereby notifying the operator in time to take the necessary action.

With the help of the 3500 frame configuration software, each channel can be programmed to perform a variety of functions, including pulse acceleration, reciprocating acceleration, reciprocating speed, and more. The paired programming of these functions ensures that up to two of them can be performed per channel in a single configuration.

In addition, the main objective of the 3500/70M is to provide continuous mechanical protection, ensuring the safe and stable operation of the equipment by comparing the monitored mechanical condition with the preset alarm set points, as well as providing basic machine information for operation and maintenance.

Overall, the 3500/70M is a powerful and flexible monitoring module that can meet the needs of various reciprocating compressor vibration monitoring, providing a strong guarantee for the safe operation of industrial equipment. However, to ensure optimum performance and long-term stability, users are advised to follow the manufacturer’s installation guide and operating manual for proper installation, configuration and maintenance.
