3674 TRICONEX 數字輸出模塊 成都陽光熹禾

3674 TRICONEX 數字輸出模塊 成都陽光熹禾

  1. 標稱電壓為24V直流電（DC）。
  2. 輸出信號為32路共用。
  3. 電壓范圍為16-30VDC，最大電壓為36VDC。
  4. 電壓降為1.5VDC（典型值）。
  5. 電源模塊負載為10瓦。
  6. 額定電流，最大值：每點2A，每10ms 10A浪涌。
  7. 負載泄漏最大為2mA。
  8. 點隔離最小為1500VDC。
  9. 共模抑制比為-85 dB (DC – 100Hz)。
  10. 輸入超量程保護為150 VDC/115 VAC連續。
分類：

描述

產品細節說明:3674 TRICONEX 數字輸出模塊

  1. 高速數字輸入：3674 模塊提供多個數字信號輸入通道，能夠快速準確地檢測輸入信號的狀態變化??。
  2. 抗干擾能力：具備較高的抗干擾能力，能夠在電磁干擾較大的環境下穩定運行??。
  3. 多種輸出類型：數字輸出模塊具有多種輸出類型，常見的有晶體管輸出型和繼電器輸出型，適應不同控制需求??。
  4. 輸出通道數量：模塊通常配備多個數字輸出通道，用于驅動外部設備如閥門、繼電器、指示燈等??。
  5. 易于集成：設計用于與Triconex及其他施耐德電氣自動化系統無縫集成，通過標準化的通信協議和接口實現高效的數據交換??。
  6. 診斷與維護功能：提供豐富的自診斷功能，幫助用戶快速識別和解決系統中的問題，降低維護成本??。
  7. 三重冗余結構：與TRICONEX 3564類似，3674也采用三重冗余設計，確保在任何一個處理器或通信通道發生故障時，系統仍能繼續運行，并保持安全??。
  8. 強大的處理能力：配備了高性能的處理器，能夠執行復雜的邏輯和控制任務??。
  9. 靈活的編程：支持多種編程語言，如梯形圖、功能塊圖和結構化文本等，方便用戶根據具體需求進行編程??。
  10. 豐富的通信接口：提供多種通信接口和協議，如以太網、串行通信等，方便與其他系統和設備進行數據交換和通信??。
  11. 故障診斷和自恢復功能：系統具有強大的故障診斷能力，能夠檢測并報告系統中的故障，同時具備一定的自恢復功能，提高系統的可靠性和穩定性

3674

產品詳情參數:3674 TRICONEX 數字輸出模塊

  • 標稱電壓為24V直流電（DC）。
  • 輸出信號為32路共用。
  • 電壓范圍為16-30VDC，最大電壓為36VDC。
  • 電壓降為1.5VDC（典型值）。
  • 電源模塊負載為10瓦。
  • 額定電流，最大值：每點2A，每10ms 10A浪涌。
  • 負載泄漏最大為2mA。
  • 點隔離最小為1500VDC。
  • 共模抑制比為-85 dB (DC – 100Hz)。
  • 輸入超量程保護為150 VDC/115 VAC連續。

3674 TRICONEX 應用領域:

該模塊設計考慮了高安全性和可靠性，適用于惡劣的工業環境，并且具備遠程I/O能力，可以與主控制器進行遠程通信和數據交換，實現更靈活的系統配置和控制策略。內置的故障診斷和報警功能能夠及時檢測和報告故障信息，降低生產中斷的風險并減少維護成本 。

TRICONEX 3674 數字輸出模塊因其高安全性、可靠性和靈活性，成為許多企業在工業自動化和過程控制系統中的首選產品，尤其在化工、石化、電力等工業領域的應用中發揮著重要作用 。

Product details: 3674 TRICONEX digital output module
High speed digital input: The 3674 module provides multiple digital signal input channels, which can quickly and accurately detect changes in the status of input signals.
Anti interference capability: It has high anti-interference ability and can operate stably in environments with high electromagnetic interference.
Multiple output types: Digital output modules have multiple output types, commonly including transistor output and relay output, to meet different control requirements.
Number of output channels: Modules are typically equipped with multiple digital output channels to drive external devices such as valves, relays, indicator lights, etc.
Easy to integrate: Designed for seamless integration with Triconex and other Schneider Electric automation systems, efficient data exchange is achieved through standardized communication protocols and interfaces.
Diagnostic and maintenance functions: Provides rich self diagnostic functions to help users quickly identify and solve problems in the system, reducing maintenance costs.
Triple redundancy structure: Similar to the TRICONEX 3564, the 3674 also adopts a triple redundancy design to ensure that the system can continue to operate and remain safe in the event of any processor or communication channel failure.
Powerful processing capability: Equipped with high-performance processors, capable of executing complex logic and control tasks.
Flexible programming: Supports multiple programming languages such as ladder diagrams, functional block diagrams, and structured text, making it convenient for users to program according to specific needs.
Rich communication interfaces: Provides multiple communication interfaces and protocols, such as Ethernet, serial communication, etc., to facilitate data exchange and communication with other systems and devices.
Fault diagnosis and self recovery function: The system has powerful fault diagnosis capabilities, which can detect and report faults in the system, and also has certain self recovery functions to improve the reliability and stability of the system
Product details and parameters: 3674 TRICONEX digital output module
The nominal voltage is 24V direct current (DC).
The output signal is shared by 32 channels.
The voltage range is 16-30VDC, with a maximum voltage of 36VDC.
The voltage drops to 1.5VDC (typical value).
The load of the power module is 10 watts.
Rated current, maximum value: 2A per point, 10A surge every 10ms.
The maximum load leakage is 2mA.
The minimum point isolation is 1500VDC.
The common mode rejection ratio is -85 dB (DC -100Hz).
The input over range protection is 150 VDC/115 VAC continuous.
3674 TRICONEX application areas:

This module design considers high security and reliability, is suitable for harsh industrial environments, and has remote I/O capabilities. It can communicate and exchange data remotely with the main controller, achieving more flexible system configuration and control strategies. The built-in fault diagnosis and alarm functions can detect and report fault information in a timely manner, reducing the risk of production interruption and lowering maintenance costs.

The TRICONEX 3674 digital output module has become the preferred product for many enterprises in industrial automation and process control systems due to its high safety, reliability, and flexibility, especially playing an important role in industrial applications such as chemical, petrochemical, and power industries.
