描述

4100-234-R 緊湊型運動控制器

艾倫-布拉德利的4100-234-R緊湊型運動控制器是一種基于微處理器的運動控制器，具有4軸和遠程I/O選項，但沒有軸鏈接選項。它使用Intel i960微處理器，處理器速度為16MHz，高效的多任務操作系統(一次最多可處理10個任務)，允許多達2,000個用戶值進程，以16位浮點數存儲在寫保護電池支持的易失性存儲器中，具有10年的電池壽命和數據保留。4100-234-R使用交流電源輸入，輸入電壓范圍為90至132伏交流，47至63赫茲，電流為3安培，I/O輸入電源為5至40伏直流(24伏標稱)，最大電流為3安培，再加上3安培，?× 1?比慢熔保險絲。它的遠程I/O選項允許通過遠程I/O適配器與設備進行順暢和輕松的通信。

4100-234-R還允許使用塊和離散傳輸直接連接到可編程邏輯控制器(PLC)。它具有4個隔離的可配置模擬輸出，控制分辨率為6位，305 μ V，輸出范圍在±10伏直流或±150毫安之間可選，在220Ω電壓電阻下具有±80 mV的最大失調電壓輸出。4100-234-R，當與flex I/O模塊一起使用時，提供更廣泛的離散I/O輸入和輸出功能。4100-234-R最多可以連接8個flex I/O模塊，以提供總共128個離散I/O點。這些分立模塊為4100-234-R提供最多20個專用光隔離分立輸入和8個光隔離，開路繼電器分立輸出。4100-234-R使用GML進行編程，RS-232C進行文件傳輸。

4100-234-R 緊湊型運動控制器

Allen Bradley’s 4100-234-R compact motion controller is a microprocessor-based motion controller with 4-axis and remote I/O options, but no axle-link option. It uses an Intel i960 microprocessor with a processor speed of 16MHz, an efficient multitasking operating system (up to 10 tasks at a time), allowing up to 2,000 user-valued processes to be stored in 16-bit floating-point numbers in write-protected battery-supported volatile memory with 10 years of battery life and data retention. The 4100-234-R uses AC power inputs with input voltage ranges of 90 to 132 volts AC, 47 to 63 Hertz, current of 3 amps, I/O input power from 5 to 40 volts DC (nominal 24 volts), maximum current of 3 amps, plus 3 amps, ?× 1? ratio slow fuse. Its remote I/O options allow smooth and easy communication with the device via a remote I/O adapter.

The 4100-234-R also allows direct connection to programmable logic controllers (PLCS) using block and discrete transmissions. It features four isolated configurable analog outputs with a control resolution of 6 bits, 305 μV, an output range between ±10 V DC or ±150 mA, and a maximum offset voltage output of ±80 mV at 220Ω voltage resistance. The 4100-234-R, when used with the flex I/O module, provides a wider range of discrete I/O input and output capabilities. The 4100-234-R can connect up to eight flex I/O modules to provide a total of 128 discrete I/O points. These discrete modules provide up to 20 dedicated optically isolated discrete inputs and 8 optically isolated, open-circuit relay discrete outputs for the 4100-234-R. The 4100-234-R uses GML for programming and the RS-232C for file transfer.
