490NRP25400 輸入信號的采樣和對輸出狀態的刷新

PLC是采用“順序掃描，不斷循環”的方式進行工作的。即在PLC運行時，CPU根據用戶按控制要求編制好并存于用戶存儲器中的程序，按指令步序號（或地址號）作周期性循環掃描，如無跳轉指令，則從條指令開始逐條順序執行用戶程序，直至程序結束。然后重新返回一條指令，開始下一輪新的掃描。在每次掃描過程中，還要完成對輸入信號的采樣和對輸出狀態的刷新等工作。
分類：

描述

490NRP25400 輸入信號的采樣和對輸出狀態的刷新

PLC是采用“順序掃描，不斷循環”的方式進行工作的。即在PLC運行時，CPU根據用戶按控制要求編制好并存于用戶存儲器中的程序，按指令步序號（或地址號）作周期性循環掃描，如無跳轉指令，則從條指令開始逐條順序執行用戶程序，直至程序結束。然后重新返回一條指令，開始下一輪新的掃描。在每次掃描過程中，還要完成對輸入信號的采樣和對輸出狀態的刷新等工作。

PLC的一個掃描周期必經輸入采樣、程序執行和輸出刷新三個階段。

PLC在輸入采樣階段：首先以掃描方式按順序?qū)⑺袝捍嬖谳斎腈i存器中的輸入端子的通斷狀態或輸入數據讀入，并將其寫入各對應的輸入狀態寄存器中，即刷新輸入。隨即關閉輸入端口，進入程序執行階段。

PLC在程序執行階段：按用戶程序指令存放的先后順序掃描執行每條指令，經相應的運算和處理后，其結果再寫入輸出狀態寄存器中，輸出狀態寄存器中所有的內容隨著程序的執行而改變。

輸出刷新階段：當所有指令執行完畢，輸出狀態寄存器的通斷狀態在輸出刷新階段送至輸出鎖存器中，并通過一定的方式（繼電器、晶體管或晶閘管）輸出，驅動相應輸出設備工作。

490NRP25400 輸入信號的采樣和對輸出狀態的刷新

PLC is the use of “sequential scanning, continuous cycle” way to work. That is, when the PLC is running, the CPU is prepared according to the user’s control requirements and exists in the user’s memory program, according to the instruction step number (or address number) for periodic cycle scanning, if there is no jump instruction, the user program is executed successively from the beginning of the instruction until the end of the program. Then a new command is returned to start the next round of scanning. In the process of each scan, it is necessary to complete the sampling of the input signal and refresh the output state.
A PLC scan cycle must be input sampling, program execution and output refresh three stages.
In the input sampling stage, PLC first reads the on-off status or input data of all the input terminals that temporarily exist in the input latch in order by scanning, and writes it into the corresponding input status register, that is, refresh the input. Then close the input port and enter the program execution phase.
PLC in the program execution stage: scan and execute each instruction according to the sequence of user program instructions stored, after the corresponding operation and processing, the result is written into the output status register, and all the contents of the output status register change with the execution of the program.
Output refresh stage: When all instructions are executed, the on-off state of the output status register is sent to the output latches in the output refresh stage, and output by a certain way (relay, transistor or thyristor) to drive the corresponding output device.
