描述

5069-L310ER CompactLogix 5380控制器模塊

5069-L310ER?是羅克韋爾自動化（Rockwell Automation）的一款可編程自動化控制器（PAC），具體是 CompactLogix 5380 控制器的一個型號。這款控制器具有集成安全功能，其安全完整性等級（SIL）為2級，適用于滿足這一SIL等級且無容錯的應用中。

5069-L310ER?控制器具有多種功能和特性，包括：

1. 內存配置：配備了1 MB的標準用戶內存和0.5 MB的安全內存，此外，還可以通過控制器附帶的1784-SD2安全數字（SD）卡提供額外的2 GB嵌入式內存。

2. 通信接口：具有雙以太網I/P端口，支持線性、星形和設備級環（DLR）拓?fù)?。這使得控制器能夠輕松地與其他設備或系統進行通信。

3. 任務處理能力：該控制器支持最多32個任務，其中31個可以被指定為標準任務，1個可以被指定為安全任務。每個任務中可以處理多達1000個程序。

4. I/O擴展能力：控制器最多可以連接24個以太網/IP網絡節點，并可以同時托管8個本地I/O模塊。這些本地I/O模塊與連接到控制器右側的Allen-Bradley I/O模塊兼容。

5. 安裝和環境要求：控制器是一個DIN導軌安裝設備，需要安裝在尺寸為35 x 7.5毫米（1.38 x 0.30英寸）的DIN導軌上，僅支持水平安裝。由于它配有開放式外殼，因此必須安裝在外殼內，以防止灰塵、污垢、油脂、腐蝕性氣體等工業污染物的侵害。面板內的溫度必須保持在0°C至60°C（32°F至140°F）之間。

6. 振動和沖擊抗性：由于控制器安裝在DIN導軌上，振動和沖擊必須分別限制在5 g @ 10…500 Hz和30 g。

為了獲得關于?5069-L310ER?的最準確和最新的技術細節，建議直接查閱羅克韋爾自動化的官方文檔、產品手冊或聯系相關的技術支持團隊。此外，考慮到工業自動化系統的復雜性和多樣性，在選擇和使用該控制器時，建議進行充分的調研和評估，以確保其滿足特定的應用需求和要求。

5069-L310ER CompactLogix 5380控制器模塊

The 5069-L310ER is a programmable Automation controller (PAC) from Rockwell Automation, specifically a model of the CompactLogix 5380 controller. The controller has integrated safety features and a Safety Integrity level (SIL) of level 2 for fault-free applications that meet this SIL level.

The 5069-L310ER controller has a variety of functions and features, including:

Memory configuration: Comes with 1 MB of standard user memory and 0.5 MB of secure memory, in addition, an additional 2 GB of embedded memory can be provided via the 1784-SD2 secure digital (SD) card included with the controller.

Communication interface: Dual Ethernet I/P ports support linear, star, and device-level loop (DLR) topologies. This allows the controller to easily communicate with other devices or systems.

Task processing capability: The controller supports up to 32 tasks, of which 31 can be designated as standard tasks and 1 can be designated as security tasks. Up to 1000 programs can be processed in each task.

I/O scaling capability: The controller can connect up to 24 Ethernet /IP network nodes and can host up to eight local I/O modules simultaneously. These local I/O modules are compatible with the Allen-Bradley I/O module connected to the right side of the controller.

Installation and Environmental requirements: The controller is a DIN rail mounting device that needs to be mounted on a DIN rail measuring 35 x 7.5 mm (1.38 x 0.30 in) and supports horizontal mounting only. Because it is equipped with an open housing, it must be installed in the housing to prevent dust, dirt, grease, corrosive gases and other industrial pollutants. The temperature inside the panel must be maintained between 0°C and 60°C (32°F to 140°F).

Vibration and shock resistance: Since the controller is mounted on a DIN rail, vibration and shock must be limited to 5 g @ 10, respectively. 500 Hz and 30 g.

For the most accurate and up-to-date technical details on the 5069-L310ER, it is recommended to consult Rockwell Automation’s official documentation, product manual, or contact the appropriate technical support team. In addition, considering the complexity and diversity of industrial automation systems, it is recommended that sufficient research and evaluation be carried out when selecting and using this controller to ensure that it meets the specific application needs and requirements.
