專爐控制系統面置:每座轉爐本體，散狀加料，余熱銀爐、煙氣凈化各用1臺PLC及操作站，轉爐本體公用部分、鼓風機房、煤氣回收輸雷各用1臺PLC及1臺操作站。1#、2#轉爐各設1臺服務器。轉爐控制系統配置。
控制系統聯接網絡共有四層: 1,設備網(DeviceNet/ProfiBUS) ; 2.控制網(余ontrolNet) : 3廠級管理網(EtherNet/P) ; 4.局城網(EtherNet/IP)，該網設置于轉爐主控室，以便轉爐主控室2座轉爐的10臺操作站和服務器的聯網使用?，F(xiàn)場設備聯接的設備網有DeviceNet、ProfiBus，如氧槍變頻器、煤氣鼓風機6KV中壓變頻器直接通過設備網卡與PLC通訊.所有1#/2#轉爐及公用部分PLC、操作站、服務器之間采用(ControlNet) 幾余控制網連為一休，實現PLC、操作站、服務器數據共享、實時交換車鑄機、精煉爐同轉一樣，采用獨立的ContrlLoix控制系統。廠級管理網(EtherNet/P) 將轉、連鑄機、LF精爐控制系統的服務器與級管理機、調度機相連接，實現主要生產、能源數據相互交換，為廠級管理和調度人員提供產生調度、決策數據.轉爐各操作站、服務器采用DELL中高端配置商用計算機。服務器、操作站系統平臺為Windows2000(服務器/客戶版)，操作站上位監控軟件為RSView32，PLC組態軟件為RSLogix5000，網絡組態軟件RSLinx(ControlVet/DeviceNet)等。轉爐本體操作畫面，轉爐在主控室分別設置一臺服務器，服務器用于網絡管理、用戶登陸控制，生產數據的管理、報表的打印，上位管理網的通訊、專業工程師的軟件開發及維護使用等。為實現ERP功能奠定基礎。在生產中服務器也可作為操作站使用。

531X305NTBANG1 專爐控制系統面置

Special furnace control system: each converter body, loose feed, waste heat silver furnace, flue gas purification with 1 PLC and 1 operating station, converter body common part, blower room, gas recovery and mine transport with 1 PLC and 1 operating station. The 1# and 2# converter are each equipped with 1 server. The control system configuration of the converter is shown in FIG. 1.
The control system connection network has four layers: 1, device network (DeviceNet/ProfiBUS); 2. Control network (residual ontrolNet) : 3 factory level management network (EtherNet/P); 4. Local city network (EtherNet/IP), the network is set in the main control room of the converter, in order to network the 10 operating stations and servers of the 2 converter in the main control room of the converter. The equipment network connected to the field equipment has DeviceNet and ProfiBus, such as the oxygen gun inverter and the 6KV medium voltage inverter of the gas blower directly communicate with the PLC through the equipment network card. All 1#/2# converter and common part PLC, operation station and server use ControlNet to connect more than one control network to realize PLC, operation station and server data sharing and real-time delivery
The casting machine and refining furnace are replaced by an independent ContrlLoix control system. The plant level management network (EtherNet/P) connects the server of the converter, continuous casting machine and LF fine furnace control system with the level management machine and scheduler to realize the exchange of main production and energy data, and provides scheduling and decision data for the plant level management and scheduler. Each operation station and server of converter adopts DELL medium and high-end commercial computer. The system platform of the server and operating station is Windows2000(server/client edition), the monitoring software of the operation station is RSView32, the PLC configuration software is RSLogix5000, and the network configuration software is RSLinx(ControlVet/DeviceNet). The operation screen of the converter body is shown in Figure 2 >
The #/2# converter is equipped with a server in the main control room, which is used for network management, user login control, production data management, report printing, communication of the upper management network, software development and maintenance of professional engineers. Lay the foundation for realizing ERP function. Servers can also be used as operation stations in production.
