描述

573-935-202C 在精密制造、機械加工等領域，振動模塊可以用于控制和調節設備的振動

不同類型的高性能振動模塊工作原理有所不同。以振動時效工藝原理為例，其主要由主控機系統、激振器、測振傳感器、控制輸出線、低噪聲屏蔽電纜、C形卡具以及彈性支撐墊組成。時效開始前，將被振構件置于橡膠支撐墊上，用C形卡具將激振器和構件剛性固定在一起。將激振器通過控制輸出線連接到主機，將傳感器通過低噪聲屏蔽電纜連接到主機，至此準備工作完成。打開主機，按啟動鍵后激振器開始工作，傳感器將振幅數據傳送給主機。

第一階段為掃頻階段，在該階段激振器從2000轉到8000轉開始掃頻，573-935-202C用于尋找構件的共振頻率。當接近構件的共振頻率時，掃頻曲線出現上升趨勢，最終達到最高點后下降，系統自動記錄該點的轉速，即為該構件的共振頻率，然后進入時效階段。

在時效階段激振器保持在共振頻率下工作，從宏觀上看構件處于共振狀態，此時激振器施加的動應力加上構件的內應力大于材料的屈服極限，使構件發生微觀塑性形變。從微觀上看，應力集中點的金屬晶體會向晶體分布較為松散的區域滑移，直至構件內應力達到均化后趨于穩定。時效前期構件內應力的均化會使曲線表現出較大的變化，應力被均化后曲線也趨于平穩。時效階段在達到設定的時間時結束。

接下來進入第二次掃頻階段，該階段同第一次掃頻階段流程相同，573-935-202C得出的曲線數據用于同第一次掃頻的曲線數據進行對比。根據振動時效機械行業標準，通過兩次掃頻數據變化來判斷消除應力的效果，兩次數據變化量越大表明消除的應力越多

573-935-202C 高性能振動模塊廣泛應用于各種需要振動檢測和控制的場景，以下是一些主要的應用場景：

安全監測系統：振動模塊可以用于門窗、保險柜等設備的安全防盜監測，當受到外力作用時，它可以感知到并發出警報。
振動控制：在精密制造、機械加工等領域，振動模塊可以用于控制和調節設備的振動，以提高產品的質量和精度。
環境監測：在地震、地質災害預警等環境監測領域，高性能的振動模塊可以用來檢測和監測微小的振動和位移，以實現對地震、地質災害的預警和防范。
機械設備狀態監測：在大型機械設備、車輛、船舶等運行過程中，振動模塊可以用于監測設備的運行狀態和故障預警，預防設備損壞和維護成本。
聲學研究：在聲音傳播、噪聲控制、音樂設備等領域，高性能振動模塊也可以用于研究和控制聲音的傳播和振動。
總之，高性能振動模塊的應用場景廣泛，涵蓋了安全防范、精密制造、環境監測、機械設備狀態監測和聲學研究等多個領域。隨著科技的發展，高性能振動模塊的性能和功能也在不斷提升，其應用場景也將不斷擴大。

573-935-202C 在精密制造、機械加工等領域，振動模塊可以用于控制和調節設備的振動

Different types of high-performance vibration modules work differently. Taking the principle of vibration aging process as an example, it is mainly composed of main control system, vibration exciter, vibration sensor, control output line, low noise shielded cable, C-shaped clamp and elastic support pad. Before the aging begins, the vibrated member is placed on the rubber support pad, and the exciter and the member are rigidly fixed together with the C-shaped clamp. Connect the shaker to the host via the control output line and the sensor to the host via the low noise shielding cable. Open the host, press the start key after the shaker starts to work, the sensor transmits the amplitude data to the host.

The first stage is the sweep stage, in which the shaker starts to sweep from 2000 to 8000 RPM, 573-935-202C is used to find the resonance frequency of the component. When approaching the resonance frequency of the component, the sweep frequency curve appears an upward trend, and finally decreases after reaching the highest point. The system automatically records the rotational speed of the point, that is, the resonance frequency of the component, and then enters the aging stage.

In the aging stage, the exciter keeps working at the resonance frequency, and the component is in the resonance state from a macroscopic point of view. At this time, the dynamic stress exerted by the exciter and the internal stress of the component are greater than the yield limit of the material, which causes the microplastic deformation of the component. From the microscopic point of view, the metal crystal at the stress concentration point will slip to the region with relatively loose crystal distribution until the internal stress of the member reaches the homogenization and tends to be stable. The curve will show great changes due to the homogenization of the internal stress in the pre-aging period, and the curve will become stable after the stress is homogenized. The prescription period ends when a set time is reached.

Next, it enters the second frequency sweep stage, which is the same as the first frequency sweep stage, and the curve data obtained from 573-935-202C is used to compare with the curve data of the first frequency sweep. According to the industry standard of vibration aging machinery, the effect of stress relief is judged by the change of the frequency data of two sweeps, and the greater the change of the data of two times, the more stress is eliminated

573-935-202C High-performance vibration modules are widely used in a variety of scenarios requiring vibration detection and control. The following are some of the main application scenarios:

Safety monitoring system: Vibration module can be used for security anti-theft monitoring of doors and Windows, safes and other equipment, when subjected to external force, it can sense and issue an alarm.
Vibration control: In precision manufacturing, machining and other fields, vibration modules can be used to control and adjust the vibration of equipment to improve the quality and accuracy of products.
Environmental monitoring: In the field of environmental monitoring such as earthquake and geological disaster warning, high-performance vibration modules can be used to detect and monitor small vibration and displacement to achieve early warning and prevention of earthquake and geological disasters.
Mechanical equipment condition monitoring: In the operation process of large mechanical equipment, vehicles, ships, etc., vibration modules can be used to monitor the operating status of equipment and fault warning, to prevent equipment damage and maintenance costs.
Acoustic research: In the fields of sound propagation, noise control, music equipment, etc., high-performance vibration modules can also be used to study and control the propagation and vibration of sound.
In short, high-performance vibration modules have a wide range of application scenarios, covering many fields such as safety prevention, precision manufacturing, environmental monitoring, mechanical equipment condition monitoring and acoustic research. With the development of science and technology, the performance and function of high-performance vibration modules are also constantly improving, and their application scenarios will continue to expand.
