描述

5SHX0660F0002 plc的選擇主要應從機型、容量、i/o模塊、電源模塊、特殊功能模塊、通信聯網能力等方面加以綜合考慮

plc的選擇主要應從機型、容量、i/o模塊、電源模塊、特殊功能模塊、通信聯網能力等方面加以綜合考慮。plc的容量包括i/o點數和用戶存儲容量兩個方面。

　　(一)i/o點數的選擇

plc平均的i/o點的價格還比較高，因此應該合理選用plc的i/o點的數量，在滿足控制要求的前提下力爭使用的i/o點少，但必須留有一定的裕量。

通常i/o點數是根據被控對象的輸入、輸出信號的實際需要，再加上10%~20%的余量來確定。

　　(二)用戶存儲容量的選擇

用戶程序所需的存儲容量大小不僅與plc系統的功能有關，而且還與功能實現的方法、程序編寫水平有關。一個有經驗的程序員和一個初學者，在完成同一復雜功能時，其程序量可能相差25%之多，所以對于初學者應該在存儲容量估算時多留裕量。

plc的i/o點數的多少，在很大程序上反映了plc系統的功能要求，因此可在i/o點數確定的基礎上，按下式估算存儲容量后，再加20%~30%的裕量。存儲容量(字節)=開關量i/o點數×10+模擬量i/o通道數×100

另外，在存儲容量選擇的同時，注意對存儲器的類型的選擇。

5SHX0660F0002 plc的選擇主要應從機型、容量、i/o模塊、電源模塊、特殊功能模塊、通信聯網能力等方面加以綜合考慮

The selection of plc should be mainly considered from the model, capacity, i/o module, power module, special function module, communication networking capability and other aspects. plc capacity includes i/o points and user storage capacity two aspects.

(A)i/o points selection

The average price of plc i/o points is still relatively high, so the number of plc i/o points should be reasonably selected, and strive to use less i/o points under the premise of meeting the control requirements, but must leave a certain margin.

Usually i/o points are determined according to the actual needs of the input and output signals of the controlled object, plus a margin of 10% to 20%.

(2) The user’s choice of storage capacity

The storage capacity required by the user program is not only related to the function of the plc system, but also related to the method of function realization and the level of program writing. An experienced programmer and a beginner can vary as much as 25 percent in the amount of programs they use to perform the same complex function, so beginners should leave a margin for storage capacity estimates.

The number of plc i/o points reflects the functional requirements of the plc system to a large extent, so it can be determined on the basis of i/o points, and then add 20% to 30% margin after estimating storage capacity according to the following formula. Storage capacity (bytes)= Number of i/o points x 10+ Number of analog i/o channels x 100

In addition, when the storage capacity is selected, pay attention to the selection of the type of storage.
