描述

5X00226G02 實現強大的顯示功能、報警功能、操作功能、報表打印功能、組態和編程功能等

分散式控制系統（Distributed Control System，簡稱DCS）是一種基于微處理器的控制系統，其設計原則是將控制功能分散到各個子系統中，而操作和管理則集中在中央控制室。這種系統采用多層分級、合作自治的結構形式，其主要特征是集中管理和分散控制。

在DCS中，5X00226G02過程控制級具體實現了信號的輸入、變換、運算和輸出等分散控制功能。過程控制級包括各種控制裝置，如過程控制單元、現場控制站、過程接口單元等，它們的結構形式大致相同，可以統稱為現場控制單元（FCU）。DCS的硬件和軟件都是按照模塊化結構設計的，系統的開發過程就是將提供的各種基本模塊根據實際需要組合成一個完整的系統，這個過程稱為系統的組態。

操作站用于顯示并記錄來自各控制單元的過程數據，是人與生產過程信息交互的操作接口。典型的操作站包括主機系統、顯示設備、鍵盤輸入設備、信息存儲設備和打印輸出設備等，主要實現強大的顯示功能、報警功能、操作功能、報表打印功能、組態和編程功能等。此外，DCS操作站還分為操作員站和工程師站。

分散控制是指系統中的控制部分表現為若干個分散的、有一定相對獨立性的子控制機構，這些機構在各自的范圍內各司其責，各行其是，互不干涉，各自完成自己的目標。5X00226G02分散控制的優點是針對性強，信息傳遞效率高，系統適應性強，特別適用于系統組織較松散的部門，如城市各交叉路口的交通管理、企業集團的一些外圍企業等。

DCS廣泛應用于電力、冶金、石化等各行各業的生產過程控制。5X00226G02是以計算機、通信和屏幕顯示技術為基礎，實現對生產過程的數據采集、控制和保護功能，并實現數據共享的多計算機監控系統。

5X00226G02 實現強大的顯示功能、報警功能、操作功能、報表打印功能、組態和編程功能等

A Distributed Control System (DCS) is a microprocessor-based control system designed to decentralize control functions to various subsystems, while operations and management are centralized in a central control room. This kind of system adopts the structure form of multi-tiered, cooperative and autonomous, and its main characteristics are centralized management and decentralized control.

In DCS, the 5X00226G02 process control stage realizes the decentralized control functions of signal input, transformation, operation and output. The process control level includes various control devices, such as process control units, field control stations, process interface units, etc., whose structural forms are roughly the same and can be collectively referred to as field control units (FCU). DCS hardware and software are designed in accordance with the modular structure, the development process of the system is to provide a variety of basic modules according to actual needs combined into a complete system, this process is called the configuration of the system.

The operation station is used to display and record the process data from each control unit, and is the operation interface for people to interact with the production process information. Typical operating station includes host system, display device, keyboard input device, information storage device and print out device, etc., mainly to achieve powerful display function, alarm function, operation function, report printing function, configuration and programming function. In addition, DCS operating stations are also divided into operator stations and engineer stations.

Decentralized control means that the control part of the system is manifested as a number of decentralized and relatively independent sub-control institutions, which perform their own responsibilities within their own scope, act independently, do not interfere with each other, and accomplish their own goals. 5X00226G02 decentralized control has the advantages of strong pertinency, high information transmission efficiency, and strong system adaptability, which is especially suitable for departments with loose system organization, such as traffic management at urban intersections and some peripheral enterprises of enterprise groups.

DCS is widely used in power, metallurgy, petrochemical and other industries of production process control. 5X00226G02 is a multi-computer monitoring system based on computer, communication and screen display technology to achieve data acquisition, control and protection of the production process, and to achieve data sharing.
