描述

685-069171-100 線性編碼器可以分為直線編碼器和拉繩編碼器

線性編碼器（Linear Encoder）是一種傳感器或讀數頭，685-069171-100用于將編碼位置轉換成模擬或數字信號。這些信號通常由數字讀出器（DRO）或運動控制器解碼為位置。線性編碼器廣泛應用于各種需要精確位置測量和控制的場合，如CNC銑床、機器人設備等。

線性編碼器可以分為直線編碼器和拉繩編碼器。直線編碼器通常由閱讀器和測量標尺組成，通過檢測閱讀器和測量標尺之間的相對位置來計算機械變化。直線編碼器一般應用于CNC銑床等高精度設備上。拉繩編碼器則是一種特殊的線性編碼器，其測量標尺可以拉伸和收縮，適用于需要測量較長距離或不規則形狀的場合。

線性編碼器按照測量類型可以分為絕對式線性編碼器和增量式線性編碼器。絕對式線性編碼器可以直接讀取出當前位置，而不需要知道之前的運動情況。增量式線性編碼器則只能測量出相對于起始位置的位移量，需要知道起始位置才能確定當前位置。

線性編碼器的工作原理涉及到各種技術，如電磁、光電、電感、電容和激光等。其中，磁柵編碼陣列和霍爾編碼陣列是線性編碼器中最常用的兩種技術。磁柵編碼陣列作為感應標尺，而霍爾編碼陣列則作為閱讀器。當霍爾元件保持一定間隙沿磁柵軸線表面移動時，線性霍爾會感測出類似正弦波信號的位移量信息。這個信號經過信號分割器處理后，可以得到精度非常高的位置信息。

總的來說，685-069171-100線性編碼器是一種重要的位置測量和控制設備，其精度和穩定性對于保證設備正常運行和提高生產效率具有重要意義。在選擇和使用線性編碼器時，需要根據實際應用場景和設備要求，選擇適合的編碼器類型和配置方式，并進行正確的安裝和配置。

685-069171-100 線性編碼器可以分為直線編碼器和拉繩編碼器

A Linear Encoder is a sensor or reading head, 685-069171-100, used to convert a coded position into an analog or digital signal. These signals are usually decoded into position by a digital reader (DRO) or motion controller. Linear encoders are widely used in a variety of applications requiring accurate position measurement and control, such as CNC milling machines, robotic equipment, etc.

Linear encoders can be divided into linear encoders and pull rope encoders. Linear encoders usually consist of a reader and a measuring scale, and calculate mechanical changes by detecting the relative position between the reader and the measuring scale. Linear encoders are generally used in high-precision equipment such as CNC milling machines. The drawstring encoder is a special linear encoder with a measuring scale that can be stretched and contracted, which is suitable for measuring longer distances or irregular shapes.

Linear encoders can be divided into absolute linear encoders and incremental linear encoders according to the measurement type. Absolute linear encoders can directly read out the current position without knowing the previous motion. Incremental linear encoders can only measure the amount of displacement relative to the starting position and need to know the starting position to determine the current position.

The working principle of linear encoders involves various technologies, such as electromagnetic, photoelectric, inductance, capacitor and laser. Among them, magnetic gate coded array and Hall coded array are the two most commonly used techniques in linear encoders. The magnetic-gate coded array acts as the sensing scale, while the Hall-coded array acts as the reader. When the Hall element keeps a certain gap and moves along the axis surface of the magnetic gate, the linear Hall will detect the displacement information similar to the sine wave signal. After the signal is processed by the signal splitter, the position information with very high precision can be obtained.

In general, 685-069171-100 linear encoder is an important position measurement and control equipment, its accuracy and stability are of great significance to ensure the normal operation of equipment and improve production efficiency. When selecting and using a linear encoder, select an appropriate encoder type and configuration mode based on actual application scenarios and device requirements, and install and configure the encoder correctly.
