描述

810-002895-002 電路板模塊

PCB(printed circuit board)即印制線路板，簡稱印制板，是電子工業的重要部件之-。幾乎每種電子設備,小到電子手表、計算器，大到計算機、通信電子設備、軍用武器系統，只要有集成電路等電子元件，為了使各個元件之間的電氣互連，都要使用印制板。印制線路板由絕緣底板、連接導線和裝配焊接電子元件的焊盤組成，具有導電線路和絕緣底板的雙重作用。它可以代替復雜的布線，實現電路中各元件之間的電氣連接，不僅簡化了電子產品的裝配、焊接工作，減少傳統方式下的接線工作量，大大減輕工人的勞動強度;而且縮小了整機體積，降低產品成本,提高電子設備的質量和可靠性。

印制線路板具有良好的產品一致性，它可以采用標準化設計，有利于在生產過程中實現機械化和自動化。同時，整塊經過裝配調試的印制線路板可以作為一個獨立的備件，便于整機產品的互換與維修。目前，印制線路板已經極其廣泛地應用在電子產品的生產制造中。

印制線路板最早使用的是紙基覆銅印制板。自半導體晶體管于20世紀50年代出現以來，對印制板的需求量急劇.上升。特別是集成電路的迅速發展及廣泛應用，使電子設備的體積越來越小，電路布線密度和難度越來越大，這就要求印制板要不斷更新。目前印制板的品種已從單面板發展到雙面板、多層板和撓性板;結構和質量也已發展到超高密度、微型化和高可靠性程度;新的設計方法、設計用品和制板材料、制板I藝不斷涌現。近年來,各種計算機輔助設計(CAD)印制線路板的應用軟件已經在行業內普及與推廣，在專門化的印制板生產廠家中，機械化、自動化生產已經完全取代了手工操作。

PCB在電子設備中具有如下功能。
(1 )提供集成電路等各種電子元器件固定、裝配的機械支承，實現集成電路等各種電子元器件之間的布線和電氣連接或電絕緣，提供所要求的電氣特
性。

(2)為自動焊接提供阻焊圖形,為元器件插裝、檢查、維修提供識別字符和圖形。

(3)電子設備采用印制板后，由于同類印制板的一致性，避免了人工接線的差錯,并可實現電子元器件自動插裝或貼裝、自動焊錫、自動檢測，保證了電子產品的質量，提高了勞動生產率、降低了成本,并便于維修。

(4)在高速或高頻電路中為電路提供所需的電氣特性、特性阻抗和電磁兼容特性。

(5)內部嵌入無源元器件的印制板，提供了-定的電氣功能，簡化了電子安裝程序，提高了產品的可靠性。

(6)在大規模和超大規模的電子封裝元器件中，為電子元器件小型化的芯片封裝提供了有效的芯片載體。

810-002895-002 電路板模塊

PCB(printed circuit board) is a printed circuit board, referred to as printed board, is an important part of the electronics industry. Almost every electronic device, small to electronic watches, calculators, large to computers, communication electronic equipment, military weapon systems, as long as there are electronic components such as integrated circuits, in order to make the electrical interconnection between the various components, to use printed boards. The printed circuit board is composed of an insulating base plate, a connecting wire and a welding pad for assembling welded electronic components, and has the dual function of conducting circuit and insulating base plate. It can replace the complex wiring, realize the electrical connection between the components in the circuit, not only simplifies the assembly of electronic products, welding work, reduce the traditional way of wiring workload, greatly reduce the labor intensity of workers; It also reduces the volume of the whole machine, reduces the cost of the product, and improves the quality and reliability of the electronic equipment.

The printed circuit board has good product consistency, and it can adopt standardized design, which is conducive to mechanization and automation in the production process. At the same time, the whole assembled and adjusted printed circuit board can be used as an independent spare part, which is convenient for the exchange and maintenance of the whole machine product. At present, printed circuit boards have been extremely widely used in the manufacturing of electronic products.

The earliest use of printed circuit boards is paper-based copper-coated printed boards. Since the advent of semiconductor transistors in the 1950s, the demand for printed boards has skyrocketed. Go up. In particular, the rapid development of integrated circuits
Widely used, the size of electronic equipment is getting smaller and smaller, and the circuit wiring density and difficulty are getting greater and greater, which requires printed boards to be constantly updated. At present, the variety of printed boards has developed from single panel to dual panel,
Multilayer and flexible plates; The structure and quality have also been developed to ultra-high density, miniaturization and high reliability; New design methods, design supplies and board making materials, and board making techniques continue to emerge. In recent years, a variety of computer aided design (CAD) printed circuit board application software has been popularized and promoted in the industry, in specialized printed board manufacturers, mechanized, automated production has completely replaced manual operation.

PCB has the following functions in electronic equipment.
(1) Provide mechanical support for fixing and assembling various electronic components such as integrated circuits, realize wiring and electrical connection or electrical insulation between various electronic components such as integrated circuits, and provide the required electrical characteristics
Sex.

(2) Provide solder resistance graphics for automatic welding, and provide identification characters and graphics for component insertion, inspection and maintenance.

(3) Electronic equipment after the use of printed boards, due to the consistency of similar printed boards, to avoid manual wiring errors, and can achieve automatic insertion or mounting of electronic components, automatic soldering, automatic detection, to ensure the quality of electronic products, improve labor productivity, reduce costs, and easy maintenance.

(4) To provide the circuit with the required electrical characteristics, characteristic impedance and electromagnetic compatibility characteristics in high speed or high frequency circuits.

(5) Printed boards embedded with passive components provide a fixed electrical function, simplify electronic installation procedures, and improve product reliability.

(6) In large-scale and ultra-large-scale electronic packaging components, it provides an effective chip carrier for the miniaturized chip packaging of electronic components.
