描述

8310? 基本對數放大器使用了跨導線性電路

對數放大器是一種特殊的放大器，其輸出信號幅度與輸入信號幅度呈對數函數關系。這種放大器主要用于將信號轉換成其等效對數值，涉及一種非線性運算放大器。對數放大器在實際應用中兼具線性和對數放大功能。當輸入信號較弱時，8310?表現為線性放大器，增益較大；而當輸入信號較強時，它轉變?yōu)閷?shù)放大器，增益隨輸入信號的增加而減小。

對數放大器在雷達設備中有特別重要的作用。它不僅可以保證雷達接收機有很寬的動態范圍，而且可以限制接收機輸出的雜波干擾電平，達到恒虛警的效果。此外，對于單脈沖雷達，對數放大器可以歸一化角誤差信號；對于動目標顯示雷達，它還可以抑制固定目標起伏。

在IC設計中，基本對數放大器使用了跨導線性電路，因此也被稱為跨導線性（Translinear）對數放大器?？鐚?dǎo)線性電路是電流模電路的主要組成部分，也是許多線性和非線性模擬集成電路的理論基礎?？鐚?dǎo)線性對數放大器基于雙極性三極管（BJT）的對數特性。理想情況下，BJT的基極-發射極電壓（UBE）與其基極電流之間呈對數關系。

此外，8310?當處理輸入信號幅度變化很大的情況時，如連續信號或接近連續的信號（如AM、單邊帶調制信號等），對數放大器也表現出其優勢。在這種情況下，自動增益控制（AGC）系統或限幅放大器可能無法有效處理，而對數放大器則能夠解決此問題。

8310? 基本對數放大器使用了跨導線性電路

A logarithmic amplifier is a special amplifier whose output signal amplitude is a logarithmic function of the input signal amplitude. This amplifier is mainly used to convert a signal into its equivalent pair value and relates to a nonlinear operational amplifier. Logarithmic amplifiers have both linear and logarithmic amplifiers in practical applications. When the input signal is weak, the 8310 behaves as a linear amplifier with large gain. When the input signal is strong, it turns into a logarithmic amplifier, and the gain decreases as the input signal increases.

Logarithmic amplifiers play a particularly important role in radar equipment. It can not only ensure that the radar receiver has a wide dynamic range, but also limit the clutter interference level of the receiver output to achieve the effect of constant false alarm. In addition, for monopulse radar, the logarithmic amplifier can normalize the angular error signal; For moving target display radar, it can also suppress fixed target fluctuation.

In IC design, basic logarithmic amplifiers use Translinear circuits and are therefore also known as translinear logarithmic amplifiers. Transconductor circuit is the main component of current mode circuit, and also the theoretical basis of many linear and nonlinear analog integrated circuits. Transwire logarithmic amplifiers are based on the logarithmic characteristics of bipolar triode (BJT). Ideally, a BJT has a logarithmic relationship between its base-emitter voltage (UBE) and its base current (ic).

In addition, the 8310 also shows its advantages when dealing with situations where the amplitude of the input signal varies greatly, such as continuous signals or near-continuous signals (such as AM, single sideband modulated signals, etc.). In such cases, an automatic gain control (AGC) system or a limiting amplifier may not be able to handle this effectively, while a logarithmic amplifier is able to solve this problem.
