8404-1001 L系列集成發動機

伍德沃德L系列集成發動機控制系統是第一個在如此緊湊 的包裝中提供如此多的發動機速度控制。L系列控制器系統是基于微處理器的，它可以很容易地被編程以匹配您生產的每臺發動機的運行參數。L系列通過軟件可選的速度設定點動態、燃油限制和啟動/停止行為提供速度控制。

傳統的支架安裝使用外部連桿，L系列控制系統可用于各種機械配置，包括- 個集成到旋轉柴油燃油泵和一個集成到節氣]體或節氣[ ]體和混合器(產品規格03222)。外部安裝的系統可以配置為順時針或逆時針(標準)軸旋轉，以增加燃油。

L系列控制裝置的高效扭矩馬達可在60°行程范圍內提供0.34N.m(0.25磅英尺)的額定扭矩，以操作燃油或空氣控制裝置(參見在整個產品溫度范圍內的扭矩性能規格)。

L系列控制功能:
-最先進的速度傳感和控制算法
-全面診斷，便于故障排除
-生產線末端可編程性簡化了庫存
-渦輪增壓柴油發動機的可選瞬態煙霧限制器
-板上提供客戶可配置的輔助輸入，以匹配您的特定應用
Stanadyne DB系列或Delphi DP200和DP2 10噴油泵的可選安裝套件提供集成控制解決方案
-使用怠速/速率1/速率2、升/降和外部模擬設置進行速度設定值調整
-可通過發動機轉速、離散輸入甚至外部信號設置兩組速度動態

8404-1001 L系列集成發動機

The Woodward L Series Integrated Engine Control system is the first to offer so much engine speed control in such a compact package. The L-Series controller system is microprocessor-based and can be easily programmed to match the operating parameters of each engine you produce. The L Series provides speed control through software-selectable speed set point dynamics, fuel limits, and start/stop behavior.

With traditional bracket mounting using external linkages, the L-Series control system can be used in a variety of mechanical configurations, including one integrated into the rotary diesel fuel pump and one integrated into the throttle body or throttle body and mixer (product specification 03222). Externally mounted systems can be configured to rotate clockwise or counterclockwise (standard) axes to increase fuel.

The efficient torque motor for the L-Series controls provides a torque rating of 0.34N.m(0.25 pound-feet) over a 60° stroke range to operate fuel or air controls (see torque performance specifications over the entire product temperature range).

L series control functions:
– State-of-the-art speed sensing and control algorithms
– Comprehensive diagnosis for easy troubleshooting
– End-line programmability simplifies inventory
– Optional transient smoke limiter for turbocharged diesel engines
– Customer-configurable auxiliary inputs are available on the board to match your specific application
The Stanadyne DB Series or optional installation kits for Delphi DP200 and DP10 fuel injection pumps provide an integrated control solution
– Speed setpoint adjustment using idle/Speed 1/ speed 2, up/down, and external analog Settings
– Two sets of speed dynamics can be set through engine speed, discrete inputs and even external signals
