描述

9852 數字頻率合成器

特性
300 MHz 內部時鐘頻率
FSK、BPSK、PSK、線性調頻、AM 操作
雙集成式 12 位數模轉換器
超高速比較器、3 ps rms 抖動
出色的動態性能
100 MHz (±1 MHz) AOUT時 SFDR 為 80 dB
4× 至 20× 可編程基準時鐘倍頻器
雙 48 位可編程頻率寄存器
雙 14 位可編程相位偏移寄存器
12 位可編程幅度調制和開/關輸出形狀調整鍵控功能
單引腳 FSK 和 BPSK 數據接口
通過 I/O 接口提供 PSK 功能
具有單引腳頻率保持功能的線性或非線性 FM 調頻功能
頻率斜升 FSK
在時鐘發生器模式下總抖動 <25 ps rms
自動雙向掃頻
Sin(x)/x 校正
簡化的控制接口
兼容 SPI 的 10 MHz 串行 2 線或 3 線
100 MHz 并行 8 位編程
3.3 V 單電源
多種關斷功能
單端或差分輸入基準時鐘
具有裸焊盤的小外形 80 引腳 LQFP 或 TQFP 封裝

9852數字頻率合成器是一款高度集成的套件，該套件使用高級 DDS 技術，外加內部高速、高性 數字頻率合成器是一款高度集成的套件，該套件使用高級 DDS 技術，外加內部高速、高性能數模轉換器，構成可數字化編程的捷變頻頻率合成器功能。在以精確時鐘源為基準時，9852 可生成高度穩定的頻率、相位和幅度可編程余弦輸出，在通信、雷達和許多其他應用中用作捷變 LO。9852的創新型高速 DDS 內核提供 48 位頻率分辨率（使用 300 MHz SYSCLK 時，調諧分辨率為 1 μHz）。為相位-幅度轉換保持 16 位分辨率可確保出色的無雜散動態范圍 (SFDR)。

9852 的電路架構允許以高達 150 MHz 的頻率生成輸出信號，并且能夠以高達每秒 1 億次的新頻率對這些輸出信號進行數字化調諧。可以針對捷變時鐘發生器應用，通過內部比較器將（外部濾波的）余弦波輸出轉換為方波。此套件提供兩個 14 位相位寄存器和單個引腳用于 BPSK 操作。

對于更高階的 PSK 操作，可以將 I/O 接口用于相變。12 位余弦 DAC 與創新型 DDS 架構結合后，可以提供出色的寬帶和窄帶輸出 SFDR。在配置有比較器的情況下，12 位控制 DAC 有助于在高速時鐘發生器應用中實現靜態占空比控制。

12 位數字倍頻器允許對余弦 DAC 輸出進行可編程幅度調制、開/關輸出形狀調整鍵控和精密幅度控制。還針對寬帶寬掃頻應用包括了線性調頻功能。9852 可編程 4× 至 20× REFCLK 倍頻器電路可在內部從較低頻率的外部基準時鐘生成 300 MHz 的系統時鐘。這可省去用戶實施 300 MHz 系統時鐘源的費用和困難。

直接 300 MHz 時鐘還適應單端或差分輸入。支持斜升 FSK 的單引腳傳統 FSK 和增強頻譜質量。9852 使用高級 0.35 μ CMOS 技術，在使用單一 3.3 V 電源的情況下提供這一高級功能。

9852 單音頻率合成器之間具有引腳兼容性。9852 可在 ?40°C 至 +85°C 的擴展工業溫度范圍內工作。

應用
捷變 LO 頻率合成
可編程時鐘發生器
用于雷達和掃描系統的 FM 線性調頻源
測試與測量設備
商用和業余 RF 激勵器

9852 數字頻率合成器

peculiarity
300 MHz internal clock frequency
FSK, BPSK, PSK, linear FM, AM operation
Dual integrated 12-bit digital-to-analog converter
Ultra high speed comparator, 3 ps rms jitter
Excellent dynamic performance
At 100 MHz (±1 MHz) AOUT, the SFDR is 80 dB
4× to 20× programmable reference clock doubler
Dual 48-bit programmable frequency registers
Dual 14-bit programmable phase shift register
12-bit programmable amplitude modulation and on/off output shape adjustment keying function
Single pin FSK and BPSK data interface
The PSK function is provided through the I/O interface
Linear or nonlinear FM frequency modulation with single-pin frequency holding
Frequency ramp up FSK
Total jitter <25 ps rms in clock generator mode
Automatic bidirectional frequency sweep
Sin(x)/x correction
Simplified control interface
10 MHz serial 2-wire or 3-wire compatible with SPI
100 MHz parallel 8-bit programming
3.3V single power supply
Multiple turn-off functions
Single ended or differential input reference clock
Small form factor 80 pin LQFP or TQFP package with bare pad

The 9852 Digital frequency synthesizer is a highly integrated kit that uses advanced DDS technology, plus internal high speed, high performance digital frequency synthesizer is a highly integrated kit that uses advanced DDS technology, plus internal high speed, high performance digital to analog converter, to form a digital programmable frequency synthesizer capabilities. When benchmarking against a precise clock source, the 9852 generates highly stable frequency, phase, and amplitude programmable cosine outputs for use as agile LO in communications, radar, and many other applications. The 9852’s innovative high-speed DDS core offers 48-bit frequency resolution (1 μHz tuning resolution when using 300 MHz SYSCLK). Maintaining 16-bit resolution for phase-to-amplitude conversion ensures excellent spury-free dynamic range (SFDR).

The 9852’s circuit architecture allows output signals to be generated at frequencies up to 150 MHz, and these output signals can be digitally tuned at new frequencies up to 100 million times per second. For agile clock generator applications, the (externally filtered) cosine wave output can be converted to a square wave by an internal comparator. This kit provides two 14-bit phase registers and a single pin for BPSK operations.

For higher order PSK operations, the I/O interface can be used for phase transitions. When combined with an innovative DDS architecture, the 12-bit cosine DAC provides excellent broadband and narrowband output SFDR. When configured with a comparator, a 12-bit control DAC facilitates static duty cycle control in high-speed clock generator applications.

The 12-bit digital frequency multiplier allows programmable amplitude modulation, on/off output shape adjustment keying, and precision amplitude control of the cosine DAC output. Linear frequency modulation is also included for wideband wide sweep applications. The 9852 programmable 4× to 20× REFCLK frequency multiplier circuit internally generates a 300 MHz system clock from an external reference clock at a lower frequency. This saves users the expense and difficulty of implementing a 300 MHz system clock source.

The direct 300 MHz clock also accommodates single-ended or differential inputs. Supports single-pin traditional FSK and enhanced spectrum quality with slant up FSK. The 9852 uses advanced 0.35μCMOS technology to deliver this advanced feature while using a single 3.3V power supply.

The 9852 single tone frequency synthesizers have pin compatibility. The 9852 can operate in an extended industrial temperature range from ?40°C to +85°C.

Apply
Agile LO frequency synthesis
Programmable clock generator
FM linear FM source for radar and scanning systems
Test and measurement equipment
Commercial and amateur RF exciter
