ABB 3HAC14550-408A | 單從驅動單元

The 3HAC14550-408A is a high-performance industrial automation product produced by ABB. Specifically, it is a single drive unit or servo driver, mainly used in ABB robot systems to provide precise power control for robot joints to achieve various movements of the robot.
3HAC14550-408A 是 ABB 公司生產的一款高性能工業自動化產品，具體來說，它是一款 單從驅動單元 或 伺服驅動器，主要用于 ABB 機器人系統中，為機器人關節提供精確的動力控制，以實現機器人的各種運動 。

This module belongs to ABB’s ACS series of products, which include various servo motors, drivers, control systems, etc., and can meet the requirements of various industrial automation applications.
該模塊屬于 ABB 的 ACS 系列產品，該系列產品包括各種伺服電機、驅動器、控制系統等，可滿足各種工業自動化應用需求 。

I. Product Overview
一、產品概述

The 3HAC14550-408A is a high-performance servo driver, specifically designed for precise motion control applications in industrial automation.
3HAC14550-408A 是一款高性能的伺服驅動器，專為工業自動化中的精確運動控制應用設計。

It can provide reliable and efficient AC servo motor control, ensuring positioning accuracy, smooth speed regulation and high-quality torque control.
它能夠提供可靠且高效的交流伺服電機控制，確保定位精度、速度平滑調節和高質量扭矩控制。

This product is widely used in various moving-intensive processes such as packaging machines, material handling systems, and printing machines.
該產品廣泛應用于包裝機、物料處理系統、印刷機等運動密集型過程的廣泛應用 。

Ii. Technical Parameters
二、技術參數

The following are the main technical parameters of 3HAC14550-408A:
以下是 3HAC14550-408A 的主要技術參數：

Parameter value
參數 數值

Model 3HAC14550-408A
型號 3HAC14550-408A

Rated power: 400 W
額定功率 400 W

Rated torque: 1.8 Newton-meters
額定扭矩 1.8 牛米

Rated speed: 3000 rpm
額定轉速 3000 rpm

Voltage range: 24 VDC to 55 VDC
電壓范圍 24 VDC 至 55 VDC

Continuous current: 8 A
持續電流 8 A

Peak current 16 A
峰值電流 16 A

The control modes include speed control, position control and torque control
控制模式 速度控制、位置控制、扭矩控制

Communication interfaces: RS-232, CANopen
通信接口 RS-232、CANopen

Dimensions: 150mm x 75mm x 40mm
尺寸 150 mm x 75 mm x 40 mm

Weight: 1.2 kilograms
重量 1.2 千克

Protection grade IP20
防護等級 IP20

Communication protocol: EtherCAT
通信協議 EtherCAT

Transmission rate: 100 Mbps
傳輸速率 100 Mbps

Interface type: RJ45
接口類型 RJ45

Power supply: 24 VDC
電源 24 VDC

Operating temperature: -20°C to +60°C
工作溫度 -20°C 至 +60°C

Material: aluminum alloy
材質 鋁合金

Iii. Functions and Features
三、功能與特點

High-precision control: Through advanced control algorithms, high-precision position, speed and torque control are achieved.
高精度控制：通過先進的控制算法，實現高精度的位置、速度和力矩控制。

High dynamic performance: It features a fast dynamic response speed, capable of quickly following command changes and achieving smooth motion control.
高動態性能：具有快速的動態響應速度，能夠迅速跟隨指令變化，實現平滑的運動控制。

High-performance EtherCAT communication interface: Supports the EtherCAT communication protocol, with a transmission rate of up to 100 Mbps, capable of connecting up to 31 devices, featuring diagnostic indicator lights, and is easy to install and maintain.
高性能 EtherCAT 通信接口：支持 EtherCAT 通信協議，傳輸速率高達 100 Mbps，可連接多達 31 個設備，具有診斷指示燈，易于安裝和維護 。

Compatibility: As an accessory or driver of the ABB brand, it has excellent compatibility with ABB’s robots and automation systems and can be conveniently integrated into existing systems.
兼容性：作為 ABB 品牌的配件或驅動器，它與 ABB 的機器人和自動化系統具有良好的兼容性，可以方便地集成到現有的系統中 。

Modular design: It is easy to integrate into various mechanical systems and is suitable for a wide range of industrial automation applications, such as mechanical manufacturing, food processing, electronic manufacturing, logistics, etc.
模塊化設計：易于集成到各種機械系統中，適用于多種工業自動化應用，如機械制造、食品加工、電子制造、物流等 。

Iv. Application Scenarios
四、應用場景

3HAC14550-408A is widely used in the following fields:
3HAC14550-408A 廣泛應用于以下領域：

Automobile manufacturing: used in processes such as welding, spraying, and assembly.
汽車制造：用于焊接、噴涂、裝配等工序。

Electronic manufacturing: For precision assembly and testing.
電子制造：用于精密裝配和測試。

Logistics industry: used for goods handling, sorting, packaging and palletizing.
物流行業：用于貨物搬運、分揀、包裝和碼垛。

Food industry: Used for food processing and packaging.
食品行業：用于食品加工和包裝。

Medical industry: used for the manufacturing and assembly of medical devices.
醫療行業：用于醫療器械的制造和裝配。

Other industrial fields: such as CNC machine tools, packaging machinery, printing machinery, textile machinery, etc.
其他工業領域：如數控機床、包裝機械、印刷機械、紡織機械等 。

V. Summary
五、總結

The 3HAC14550-408A is a high-performance servo driver featuring high precision, high dynamic performance, and high reliability, making it suitable for a wide range of industrial automation applications.
3HAC14550-408A 是一款高性能的伺服驅動器，具有高精度、高動態性能、高可靠性等特點，適用于多種工業自動化應用。

It achieves precise position, speed and torque control through advanced control algorithms and efficient power electronics technology, and is widely used in fields such as robots, packaging machinery and printing machinery.
它通過先進的控制算法和高效的功率電子技術，實現了精確的位置、速度和力矩控制，廣泛應用于機器人、包裝機械、印刷機械等領域。

Its modular design and excellent compatibility enable it to be easily integrated into existing industrial automation systems, enhancing production efficiency and product quality.
其模塊化設計和良好的兼容性使其能夠輕松集成到現有的工業自動化系統中，提高生產效率和產品質量 。
