ABB PCD235A101 | 3BHE032025R0101 | 高性能勵磁控制模塊

PCD235A101 3BHE032025R0101 is a high-performance excitation control module produced by ABB, which is widely used in the field of industrial automation, especially in power generation systems.
PCD235A101 3BHE032025R0101 是 ABB 公司生產的一款高性能勵磁控制模塊，廣泛應用于工業自動化領域，特別是在電力發電系統中。

It is mainly used to control the excitation system of the generator, ensuring the stability of the generator’s output voltage and the reliability of the system.
它主要用于控制發電機的勵磁系統，確保發電機輸出電壓的穩定性和系統的可靠性。

Product function
產品功能

The main functions of this module include:
該模塊的主要功能包括：

Excitation control: By adjusting the excitation current, the output voltage and frequency of the generator are controlled to ensure the stable operation of the power system.
勵磁控制：通過調節勵磁電流來控制發電機的輸出電壓和頻率，確保電力系統的穩定運行。

Voltage stabilization function: Ensures that the output voltage of the generator remains within the specified range, maintaining the stability of the power system.
電壓穩定功能：確保發電機輸出電壓在指定范圍內，維持電力系統的穩定性。

Communication interface: Supports multiple communication protocols (such as RS485, Modbus, etc.), facilitating data exchange with other control systems and monitoring devices.
通信接口：支持多種通信協議（如 RS485、Modbus 等），便于與其他控制系統和監控設備進行數據交換。

Monitoring and Diagnosis: It can monitor the operating status of the excitation system in real time, promptly detect faults and provide alarm information.
監測與診斷：能夠?qū)崟r監測勵磁系統的運行狀態，及時檢測故障并提供報警信息。

Programmability: Supports user-defined programming to meet specific excitation system requirements.
可編程性：支持用戶自定義編程，以滿足特定的勵磁系統需求。

Technical parameters
技術參數

Parameter value
參數 數值

Model PCD235A101 3BHE032025R0101
型號 PCD235A101 3BHE032025R0101

Input voltage: 24V DC or 380-480 VAC (three-phase)
輸入電壓 24V DC 或 380-480 VAC（三相）

Output voltage: 0-380 VAC (three-phase) or 0-400V
輸出電壓 0-380 VAC（三相）或 0-400V

Rated current: 52 A or 100 A
額定電流 52 A 或 100 A

Rated power: 25 kVA or 38 kW
額定功率 25 kVA 或 38 kW

Control accuracy ±0.5%
控制精度 ±0.5%

The response speed is less than 100 ms
響應速度 <100 ms

The operating temperature range is -10°C to +40°C or -20°C to +70°C
工作溫度范圍 -10°C 至 +40°C 或 -20°C 至 +70°C

Protection grade: IP20 or IP65
防護等級 IP20 或 IP65

The external dimensions are 300 x 200 x 100 mm
外形尺寸 300 x 200 x 100 mm

Weight: 1.5 kg
重量 1.5 kg

Application scenarios
應用場景

This module is widely applied in the following fields:
該模塊廣泛應用于以下領域：

Power system: Especially in power plants such as thermal power plants, hydropower stations and nuclear power stations, it is used to control the excitation system of generators.
電力系統：特別是在火力發電廠、水電站和核電站等發電站中，用于控制發電機的勵磁系統。

Industrial automation: In manufacturing, energy and process industries, it is used to control the motors of various production equipment, such as conveyors, pumps, fans, etc.
工業自動化：在制造業、能源和過程工業中，用于控制各種生產設備的電機，如輸送機、泵、風機等。

HVAC system: It is used in HVAC systems to control equipment such as fans and water pumps.
HVAC 系統：在暖通空調系統中用于控制風機、水泵等設備。

Other industrial applications: such as elevators, cranes, textile machinery and other occasions where AC motors need to be controlled.
其他工業應用：如電梯、起重機、紡織機械等需要控制交流電動機的場合。

Summary
總結

PCD235A101 3BHE032025R0101 is a high-performance and highly reliable excitation control module, suitable for a variety of application scenarios in industrial automation and power systems.
PCD235A101 3BHE032025R0101 是一款高性能、高可靠性的勵磁控制模塊，適用于工業自動化和電力系統中的多種應用場景。

It features precise control capabilities, flexible configuration options and powerful communication functions, which can effectively enhance the efficiency and stability of the system.
它具備精確的控制能力、靈活的配置選項和強大的通信功能，能夠有效提高系統的效率和穩定性。
