描述

AXLINK100 以太網和現場總線之間的通用網關

以太網正在成為自動化技術的主流通信媒介。aXlink100是自動化x軟件(4.7及更高版本)的新設備，可實時連接Profibus和以太網。

功能aXlink100
>實時協議(Xlink)>高帶寬
>支持冗余>防震冗余切換
>不同拓?fù)鋺?yīng)用(線、環、樹、樹冗余拓?fù)?>環形拓?fù)?，無需昂貴的光纖布線
>系統最大支持16個aXlink100 >冗余供電24V DC
>無需配置即可交換(地址切換)
>通過LED和協議進行診斷>頂帽導軌安裝> Driver for automationX from version 4.7
>其他司機應要求

aXlink100將以太網與Profibus互連，其中使用了automationx開發的實時以太網協議Xlink。aXlink100集成了兩個以太網接口，可作為8P8C (RJ45)或光纖選項，以及Profibus-DP主接口。這些接口允許多種系統和網絡配置。

因此，該設備允許通過CAT5電纜配置電環或通過星形布局網絡中的交換機配置網絡和/或服務器冗余。因此，每個單元最多可以連接16個ProfibusMaster (aXlink100)和124個Profibus-DP slave到automationX。

AXLINK100 以太網和現場總線之間的通用網關

Ethernet is becoming the prevailing communication medium in automation technology. The aXlink100, the newequipment available for the automationX software (version 4.7 and higher), connects Profibus with Ethernet inreal time.

Features aXlink100
> Real-Time protocol (Xlink)> High bandwith
> Redundancy capable> Shockproof redundancy change-over
> Different topologies application (line, ring, tree, tree topology redundant)> Ring topology without expensive optic fibre cabling
> Up to 16 aXlink100 per system> Redundant power supply 24V DC
> Exchangeable without configuration (address switch)
> Diagnostics via LED and protocol> Top hat rail mounting> Driver for automationX from version 4.7
> Other drivers on request

The aXlink100 interconnects Ethernet with Profibus, inwhich Xlink, a real time Ethernet protocol developed byAutomationX, is used. The aXlink100 incorporates twoEthernet interfaces, which are available as 8P8C (RJ45)or optic fibre option, as well as a Profibus-DP master interface. These interfaces allow a multiplicity of system andnetwork configurations.

Therefore this equipment allows the configuration of anelectrical ring via CAT5 cabling or a network and/or serverredundancy via switches in a star layout network with thisequipment. Thus it is possible to link up to 16 ProfibusMaster (aXlink100) with up to 124 Profibus-DP slaves perunit to automationX.
