描述

CC-PAON01 模擬量輸入輸出模塊卡件

1、打開控制站柜門，觀察卡件是否工作正常，有無故障顯示；
2、從每個操作站實時監控的故障診斷中觀察是否存在故障，并進行記錄；
3、檢查電源箱是否工作正常，電源風扇是否工作，5V、24V指示燈是否正常，測量記錄各電壓值；
4、備份組態、PID參數、驅動以及其他需要的重要數據；
5、檢查供電冗余，供電冗余包括交流供電冗余和直流供電冗余。交流供電冗余：通過分別斷開冗余交流~220VAC進線的一路，系統有一半的交流供電回路失電，但系統應仍然可以正常工作。直流供電冗余測試方法如下：
（1）先斷一路電源箱電源，測量每一機籠機籠母板電源端子上5V、24V的電壓；
（2）先通上一路電源箱電源，再斷另外一路電源箱電源，再測量每一機籠母板電源端子上5V、24V的電壓。電源箱5V輸出電壓應在5.10V～5.25V之間，電源箱24V輸出電壓應在23.00V～25.00V之間。如果電壓偏差較大需要及時檢查處理，否則會影響卡件的正常工作。
6、網線及布置檢查，檢查網絡線纜通斷情況，確認連接處是否接觸良好，并及時更換故障線纜；
7、UPS測試：通過斷開UPS交流進線，測試UPS電池供電能力。UPS電池應定期放電，一般建議每月一次，放電方法：斷開UPS交流供電采用電池供電，至電池即將釋放完為止。
以上檢查主要事先了解系統的運行狀態，如有不正常的現象可以在停車時及時解決。

CC-PAON01 模擬量輸入輸出模塊卡件

1, open the door of the control station cabinet, observe whether the card works normally, there is no fault display;
2, from the real-time monitoring of each operation station fault diagnosis to observe whether there is a fault, and record;
3. Check whether the power box works properly, whether the power fan works, and whether the 5V and 24V indicators are normal. Then measure and record the voltage.
4, backup configuration, PID parameters, drivers and other important data needed;
5. Check the power supply redundancy. The power supply redundancy includes AC power supply redundancy and DC power supply redundancy. Ac power supply redundancy: By disconnecting one of the redundant AC to 220VAC input lines, half of the AC power supply circuit of the system loses power, but the system can still work normally. The test method for DC power supply redundancy is as follows:
(1) First cut off the power supply of one power box, and measure the 5V and 24V voltage on the power supply terminal of the mother board of each cage;
(2) Power on one power box, then power off the other power box, and then measure the 5V and 24V voltage on the power terminal of each cage motherboard. The 5V output voltage of a power box ranges from 5.10V to 5.25V, and the 24V output voltage of a power box ranges from 23.00V to 25.00V. If the voltage deviation is large, it needs to be checked in time, otherwise it will affect the normal work of the card.
6. Check the network cable and layout, check the network cable connection, confirm whether the connection is in good contact, and replace the faulty cable in time;
7, UPS test: By disconnecting the UPS AC line, test the UPS battery power supply capability. The UPS battery should be discharged periodically (once a month is recommended). Discharge method: Turn off the UPS AC power supply Use the battery power supply until the battery is about to be discharged.
The above checks mainly understand the operating status of the system in advance, and if there is an abnormal phenomenon, it can be solved in time when stopping.
