描述

CDP-01-MH DAC-00X傳感器

CDP-01設置通常會導致不正確或不需要的導向特性。故障和故障處理步驟在cdp-01參考手冊“頻繁設置錯誤”一章中有更詳細的描述。下面的解釋。故障診斷-故障處理故障:自動模式下，傳感器移動方向錯誤。補救方法:選擇“手動”模式，在邊緣傳感器模式(LED 10點亮)下改變驅動器3的極性(導向方向)。參考:CDP-01參考手冊，章節:“改變導向方向”故障:在自動模式下，芯軸移動方向錯誤。補救措施:選擇“手動”模式，并在特殊傳感器模式(led 11和12亮)下改變驅動器2的極性(導向方向)。參考:CDP-01參考手冊，章節:“改變引導方向”故障:在伺服中心模式下，傳感器移動錯誤的方向。補救方法:選擇“手動”模式，改變驅動器3的伺服中心極性。參考資料:CDP-01參考手冊，章節:“伺服中心極性”。故障:在伺服中心模式下，芯軸移動到行程的任何一端，而不是到其行程的中心。補救方法:選擇“手動”模式，改變驅動2的伺服中心極性。參考資料:CDP-01參考手冊，章節:“伺服中心極性”。故障:在自動模式下，芯棒沒有準確跟隨傳感器。補救措施:執行本文檔中的“啟動/傳感器定位器與芯軸比率校準”程序

Fife CDP-01控制器

高級控制器提供自動設置功能,可實現快速、準確的操作

可切換115/220 VAC 50/60 Hz操作

于各種功能的并行接口:6個輸入(遠程控制)，2個輸出(警報或指示燈)

自動調整連接的Fife電機

內置放大器,用于使用紅外傳感器進行透明網頁檢測

自動傳感器控制-傳感器信號佚(即斷紙、卷筒末端)將自動切換到手動模式

CDP-01-MH DAC-00X傳感器

CDP-01 Settings often result in incorrect or unwanted orientation features. The fault and troubleshooting procedure are described in more detail in the chapter “Frequently Setting Errors” in the cdp-01 Reference manual. The following explanation. Fault Diagnosis – Troubleshooting Fault: The sensor moves in an incorrect direction in automatic mode. Remedy: Select “Manual” mode and change the polarity (guiding direction) of driver 3 in edge sensor mode (LED 10 lit). Reference :CDP-01 Reference Manual, section: “Change Direction” Fault: In automatic mode, the mandrel moves in the wrong direction. Remedy: Select “Manual” mode and change the polarity (guiding direction) of driver 2 in special sensor mode (led 11 and 12 on). Reference :CDP-01 Reference Manual, Section: “Changing the Guidance Direction” Fault: In servo-centered mode, the sensor moves in the wrong direction. Remedy: Select “Manual” mode and change the servo center polarity of drive 3. Reference :CDP-01 Reference Manual, Section: “Servo Center Polarity”. Failure: In servo center mode, the mandrel moves to either end of the stroke instead of to the center of its stroke. Remedy: Select “Manual” mode and change the servo center polarity of drive 2. Reference :CDP-01 Reference Manual, Section: “Servo Center Polarity”. Fault: In automatic mode, the mandrel does not accurately follow the sensor. Remedy: Perform the “Start/Sensor Positioner to mandrel ratio Calibration” procedure in this document

Fife CDP-01 controller

The advanced controller provides automatic Settings for fast and accurate operation

Can switch 115/220 VAC 50/60 Hz operation

Parallel interface for various functions :6 inputs (remote control), 2 outputs (alarm or indicator)

Automatically adjust the connected Fife motor

Built-in amplifier for transparent web page detection using infrared sensors

Automatic sensor control – Lost sensor signals (i.e., broken paper, reel end) will automatically switch to manual mode
