描述

CE06250-2G308B1 增量編碼器

特征：
增量編碼器
扭矩更新高達 16 kHz
5V 至 24V 工作電壓
兩個雙向 RS422 I/O
兩個模擬輸入
科爾摩根/丹納赫 Motion SERVOSTAR CD SynqNet 驅動器是一款基于經過現場驗證的 SERVOSTAR CD 驅動器系列的 SynqNet 伺服驅動器。功率級與CD相同，而控制級是專用的SynqNet設計。CD SynqNet 設計為扭矩驅動器，扭矩命令由 SynqNet 控制器以高伺服更新速率提供。提供廣泛的 I/O 支持，包括特定功能輸入（如限位開關、原位開關和制動器）以及眾多通用 I/O。CD SynqNet 提供 N 分頻功能，使其能夠被編程為每 N 個驅動器編碼器計數器寄存器產生一個輸出脈沖。
SynqNet 是一款高性能全數字同步網絡，專為多軸運動控制應用而設計。SynqNet 的物理層基于 IEEE 802.3 標準，用于以太網的物理層 100BASE-TX，而 SynqNet 的數據鏈路和應用層是專門為運動控制應用而設計的。100BASE-TX介質系統基于ANSI TP-PMD物理介質標準中公布的規范。100BASE-TX系統通過兩對電線運行，一對用于“接收”數據信號，另一對用于“發送”數據信號。
CE06250：
? 反饋：編碼器
? 額定電流：6 A
版本：3 相
配置：
? 輸入電壓：115/230 VAC
? 輸入電流：10/7.8 安培/相
? 230 VAC 時的輸入功率：1.8/2.8 KVA
? 輸出電壓：115/230 VAC
? 輸出電流：6 安培/相
? 230 VAC 時的輸出功率：1.4/2.2 KVA

CE06250-2G308B1 增量編碼器

Features:
Incremental encoder
Torque updates up to 16 kHz
Operating voltage from 5V to 24V
Two two-way RS422 I/O
Two analog inputs
Kors Morgen/Danaher Motion SERVOSTAR CD SynqNet Drive is a SynqNet servo drive based on the field-proven SERVOSTAR CD drive family. The power level is the same as the CD, while the control level is a dedicated SynqNet design. CD SynqNet is designed as a torque driver and torque commands are provided by the SynqNet controller at a high servo update rate. Extensive I/O support is available, including specific function inputs such as limit switches, in-situ switches, and brakes, as well as numerous general-purpose I/ OS. CD SynqNet provides an n-division function that enables it to be programmed to produce one output pulse per N driver encoder counter registers.
SynqNet is a high-performance, fully digital synchronous network designed for multi-axis motion control applications. SynqNet’s physical layer is based on the IEEE 802.3 standard for Ethernet’s physical layer 100BASE-TX, while SynqNet’s data link and application layer are specifically designed for motion control applications. The 100BASE-TX media system is based on the specifications published in the ANSI TP-PMD Physical Media Standard. The 100BASE-TX system operates through two pairs of wires, one for “receiving” data signals and the other for “sending” data signals.
CE06250:
? Feedback: encoder
? Rated current: 6 A
Version: 3 phases
Settings:
? Input voltage: 115/230 VAC
? Input current: 10/7.8 amps/phase
? Input power at 230 VAC: 1.8/2.8 KVA
? Output voltage: 115/230 VAC
? Output current: 6 amps/phase
? Output power at 230 VAC: 1.4/2.2 KVA
