CI860 通信接口基金會現場總線HSE
如果需要訪問AC 800M控制器中的FF過程變量，則使用CI860(通信接口基金會現場總線HSE)建立HSE子網與控制器之間的連接。
然后，可以從AC 800M控制器中的IEC 61131應用程序訪問基金會現場總線的HSE過程數據。為此，CI860模塊將FF信號的值和狀態部分映射到IEC 61131應用程序，反之亦然。
CI860由處理器單元供電，通過cex總線，因此不需要任何額外的外部電源。
特點和優點
CI860支持冗余模式
在一臺ac800m上最多可以冗余放置12個CI860模塊，每個CI860模塊可以連接到同一個或單獨的基金會現場總線HSE子網。
ABB基金會現場總線連接設備LD800HSE/LD 800HSE EX作為HSE子網和多達四個獨立H1鏈路之間的網關。
CI860 通信接口基金會現場總線HSE
If there is a need to have access to FF process variables in the AC 800M controller, connectivity between the HSE subnet and the controller is established with the CI860 – the Communication Interface FOUNDATION Fieldbus HSE.
Then?FOUNDATION Fieldbus process data on HSE can be accessed from the IEC 61131 applications in the AC 800M controllers. For this purpose, the CI860 module maps the value and status parts of the FF signals to the IEC 61131 application and vice versa.
The CI860 is powered by the processor unit, via the CEX-Bus, and therefore does not require any additional external power source.
Features and benefits
The CI860 can be used in redundant mode
Up to twelve CI860 modules can be placed at one AC800 M also in redundant mode, and each of them can be connected to the same or to a separate FOUNDATION Fieldbus HSE subnet.
The ABB FOUNDATION Fieldbus Linking Device LD800HSE/LD 800HSE EX acts as a gateway between the HSE subnet and up to four separate H1 links.
