描述

CR215GH87 對故障做初步處理并根據發生故障的類型向用戶上報故障代碼

CR215GH87控制器模塊的功能主要包括以下幾個方面：

運動控制：這是控制器模塊最核心的功能。根據接收到的運動命令，控制器進行運動學解算或軌跡規劃運算，得到每個伺服控制周期內各個關節的角度值，并發送到伺服驅動系統，使機器人的末端可以在三維空間中完成指定的路徑或姿態變化。

I/O控制：包括機器人控制器的通用I/O端口和EtherCAT擴展I/O板。主要負責對外界信號進行響應或輸出，如機器人末端工具啟動與停止控制、機器人的急停信號、生產線傳感器的檢測信號響應等。

故障處理：對故障做初步處理并根據發生故障的類型向用戶上報故障代碼，或者接受用戶輸入的故障復位指令。

參數設置：主要是對控制器的配置參數做一些設置，如EtherCAT通信對象映射參數、串口通信波特率等。

數據緩沖與交換：在數據輸入和輸出時進行緩沖，并實現CPU與控制器之間、控制器與設備之間的數據交換。

差錯控制：對由I/O設備傳送來的數據進行差錯檢測，若發現傳送中出現了錯誤，通常是將差錯檢測碼置位，并向CPU報告，CPU將本次傳送來的數據作廢，并重新進行一次傳送，保證數據輸入的正確性。

算法操作：控制器模塊的作用主要是在獲得電機電流、位置信號、斬波電流參考值IRef及占空比Duty等數據后，進行相應的算法操作，生成各相上下功率管的開關控制信號，以合理有序地控制電機正常工作。

CR215GH87 對故障做初步處理并根據發生故障的類型向用戶上報故障代碼

The functions of CR215GH87 controller module mainly include the following aspects:

Motion control: This is the most core function of the controller module. According to the received motion commands, the controller performs kinematic calculation or trajectory planning operation, obtains the Angle value of each joint in each servo control cycle, and sends it to the servo drive system, so that the end of the robot can complete the specified path or attitude change in three-dimensional space.

I/O control: Includes a universal I/O port for the robot controller and EtherCAT extended I/O board. Mainly responsible for the response or output of external signals, such as robot end tool start and stop control, robot emergency stop signal, production line sensor detection signal response, etc.

Troubleshooting: Perform preliminary troubleshooting and report the fault code to the user based on the fault type, or accept the fault reset instruction entered by the user.

Parameter setting: Mainly set some configuration parameters of the controller, such as EtherCAT communication object mapping parameters and serial port communication baud rate.

Data buffering and exchange: buffering during data input and output, and data exchange between CPU and controller, controller and device.

Error control: Error detection is performed on the data transmitted by the I/O device. If an error is found in the transmission, the error detection code is set and reported to the CPU. The CPU invalidates the data and transmits it again to ensure the correctness of the data input.

Algorithm operation: The function of the controller module is to carry out the corresponding algorithm operation after obtaining the data of the motor current, position signal, chopper current reference value IRef and Duty cycle duty, etc., to generate the switch control signal of the upper and lower power tube of each phase, so as to control the normal operation of the motor in a reasonable and orderly way.
