DS200DTBAG1AAA 數字觸點端子板

產品描述
數字接觸端子板DS200DTBAG1AAA由通用電氣生產，是Mark V系列的一部分，具有兩個端子排，最多連接95根電線。該單元還具有五個跳線和兩個2針連接器。終端塊連接發送和接收驅動器使用的信息的信號線。GE數字接觸端子板DS200DTBAG1AAA上最多可連接190根電線，因此您必須意識到可能對其他組件和板造成的損壞。拆卸端子時需使用螺絲刀松開端子，以免碰傷或刮傷其他部件。為了防止這種情況，用一只手引導螺絲刀到你想要松開的端子。

當您從DS200DTBAG1AAA移除信號線時，請嘗試將它們移動到一側并避開其他板。如果可能，請?jiān)诎惭b更換板之前重新安裝信號線，以限制損壞驅動器中易碎板的機會。如果你可以連接電線，只從側面握住板，用兩只手。小心地將單板推入機柜，并對準機架上安裝單板的孔位。更換部件時，必須佩戴防靜電腕帶，防靜電腕帶的一端必須固定在未涂漆的金屬結構上。

當將DS200DTBAG1AAA型號連接到Mark V DS200系列中的其他型號時，使用了四種連接方式。可選的連接方式有J12、JQR、JQS/T、JY;所有這些連接都有其特定的功能。例如，雖然在電路板上提供了JQS/T連接，但很少使用。

DS200DTBAG1AAA 數字觸點端子板

Product Description
Produced by General Electric as part of the Mark V series, the?Digital Contact Terminal Board DS200DTBAG1AAA features two terminal blocks that?connect a maximum of 95 wires.?This unit also features five?jumpers and two 2-pin connectors. The terminal blocks attach signal wires that send and receive information used by the drive. The potential is for a maximum of 190 wires attached to the GE Digital Contact Terminal Board DS200DTBAG1AAA,?so you must be aware of the damage that can be caused to the other components and boards. A screwdriver is used to loosen the terminal to remove the wires meaning it might hit or scratch other components when uninstalling. To prevent that,?use one hand to guide the screwdriver to the terminal you want to loosen.

As you remove the signal wires from the DS200DTBAG1AAA, try to move them to one side and out of the way of the other boards. If possible, reinstall the signal wires before you install the replacement board to limit the opportunity to damage the fragile boards in the drive. If you can attach the wires, hold the board from the sides only and use two hands. Carefully maneuver the board into the cabinet and align the holes with the holes in the rack where you will install the board. When you perform the replacement, it is necessary to wear a wrist strap and have the end of the strap attached to a metal structure that is not painted.

There are four?connections?used when connecting the?DS200DTBAG1AAA model to other models within the Mark V DS200 series. The available connections are J12, JQR, JQS/T, and JY;?all of these connections?have their own specific function. For example, while the JQS/T connection is offered on the board, it is sparingly used.
