描述

產品細節說明:FC-RUSIO-3224?? Honeywell 遠程通用安全I/O模塊

• 32個I/O通道，支持多達32個獨立傳感器連接。
• 支持模擬和數字輸入/輸出。
• HART通信，便于遠程配置和監控。
• 24Vdc電源供電。
• 隔離的輸入和輸出，防止噪聲和干擾。
• 可配置的輸入和輸出范圍。
• 支持多種I/O類型，包括數字、模擬和熱電偶輸入和輸出。
• 熱插拔模塊，冗余電源。
• 背板診斷和監控。

產品詳情參數:FC-RUSIO-3224?? Honeywell 遠程通用安全I/O模塊

• 工作溫度范圍：外部模塊溫度：-40°C至+70°C，內部模塊溫度：-40°C至+90°C。
• 存儲溫度：-40°C至+85°C。
• 相對濕度：10%至95%（非冷凝）。
• 污染等級：2級或更好。
• 認證：CE；UL, TUV待定。
• 電源電壓：24 Vdc -15%至+30%。
• 電源電流：最大300mA（無現場負載）。
• 尺寸（長x寬x高）：7.24 cm x 16.51 cm x 14.5 cm。
• 重量：0.7 Kg。

FC-RUSIO-3224?? Honeywell? 應用領域:

Honeywell FC-RUSIO-3224是一款遠程通用安全I/O模塊，它是Honeywell Experion PKS DCS系統的一部分，用于將現場設備連接到DCS系統，并且可以安裝在遠程位置。該模塊具有32個I/O通道，可以配置為模擬或數字輸入/輸出，并且支持HART通信，允許遠程配置和監控現場設備。FC-RUSIO-3224適用于多種應用，包括過程控制、樓宇自動化、電力生成、油氣生產等。

Product Details: FC-RUSIO-3224 Honeywell Remote Universal Safety I/O Module
32 I/O channels, supporting up to 32 independent sensor connections.
Supports analog and digital input/output.
HART communication facilitates remote configuration and monitoring.
Powered by a 24Vdc power supply.
Isolated input and output to prevent noise and interference.
Configurable input and output ranges.
Supports multiple I/O types, including digital, analog, and thermocouple inputs and outputs.
Hot swappable module, redundant power supply.
Backboard diagnosis and monitoring.
Product Details and Parameters: FC-RUSIO-3224 Honeywell Remote Universal Safety I/O Module
Operating temperature range: External module temperature: -40 ° C to+70 ° C, internal module temperature: -40 ° C to+90 ° C.
Storage temperature: -40 ° C to+85 ° C.
Relative humidity: 10% to 95% (non condensing).
Pollution level: Level 2 or better.
Certification: CE; UL and TUV are yet to be determined.
Power supply voltage: 24 Vdc -15% to+30%.
Power supply current: maximum 300mA (no on-site load).
Dimensions (length x width x height): 7.24 cm x 16.51 cm x 14.5 cm.
Weight: 0.7 Kg.

FC-RUSIO-3224 Honeywell application areas:

Honeywell FC-RUSIO-3224 is a remote universal safety I/O module that is part of the Honeywell Expert PKS DCS system. It is used to connect field devices to the DCS system and can be installed in remote locations. This module has 32 I/O channels, can be configured as analog or digital input/output, and supports HART communication, allowing remote configuration and monitoring of field devices. FC-RUSIO-3224 is suitable for various applications, including process control, building automation, power generation, oil and gas production, etc.
