G122-824A002?? MOOG 伺服放大器 成都陽光熹禾

G122-824A002?? MOOG 伺服放大器 成都陽光熹禾

  • 輸入信號：支持兩路單端信號（±10V或4-20 mA）和一路差分信號（±10V）。
  • 輸出信號：電流輸出為0-2 A，電壓輸出為±10V。
  • 增益調節：比例增益可調范圍為1至1000，積分增益可調范圍為0至0.01 s^-1。
  • 滯后：可選擇55 ms滯后。
  • 電源要求：24 VDC。
  • 工作溫度范圍：-40°C至70°C。
  • 外殼防護等級：IP66/NEMA 4X。
  • 尺寸：224 mm x 168 mm x 89 mm。
  • 重量：約2.7 kg。
  • 安裝方式：支持DIN導軌或墻壁安裝。
分類：

描述

產品細節說明:G122-824A002?? MOOG 伺服放大器

  • 寬輸入電壓范圍：能夠適應100-240 VAC的電壓輸入。
  • 連續輸出電流：具有24 A的連續輸出電流能力。
  • 峰值輸出電流：能夠提供高達48 A的峰值輸出電流。
  • 可編程增益和積分時間：用戶可以根據應用需求調整增益和積分時間。
  • 過流、過壓和欠壓保護：內置的保護功能確保系統的安全運行。
  • 高功率密度和低噪聲：設計用于減少干擾，提供更清晰的信號。
  • 速度和位置環路閉環控制：提供精確的速度和位置控制。
  • 故障保護：在出現異常情況時能夠保護系統不受損害。

G122-824A002

產品詳情參數:G122-824A002?? MOOG 伺服放大器

  • 輸入信號：支持兩路單端信號（±10V或4-20 mA）和一路差分信號（±10V）。
  • 輸出信號：電流輸出為0-2 A，電壓輸出為±10V。
  • 增益調節：比例增益可調范圍為1至1000，積分增益可調范圍為0至0.01 s^-1。
  • 滯后：可選擇55 ms滯后。
  • 電源要求：24 VDC。
  • 工作溫度范圍：-40°C至70°C。
  • 外殼防護等級：IP66/NEMA 4X。
  • 尺寸：224 mm x 168 mm x 89 mm。
  • 重量：約2.7 kg。
  • 安裝方式：支持DIN導軌或墻壁安裝。

G122-824A002?? MOOG 應用領域:

MOOG G122-824A002是一種高性能的伺服放大器，廣泛應用于工業自動化、機器人、數控機床和其他需要精確運動控制的領域。這款伺服放大器以其高放大和功率輸出能力、廣泛的伺服電機兼容性、精密運動控制的先進控制算法以及堅固的結構而著稱。它能夠提供穩定的電流和精確的位置控制，實現高效的加工過程和生產效率。

Product details: G122-824A002 MOOG servo amplifier
Wide input voltage range: able to adapt to voltage inputs of 100-240 VAC.
Continuous output current: With a continuous output current capability of 24 A.
Peak output current: capable of providing a peak output current of up to 48 A.
Programmable gain and integration time: Users can adjust the gain and integration time according to application requirements.
Overcurrent, overvoltage, and undervoltage protection: The built-in protection function ensures the safe operation of the system.
High power density and low noise: designed to reduce interference and provide clearer signals.
Speed and position closed-loop control: providing precise speed and position control.
Fault protection: It can protect the system from damage in case of abnormal situations.
Product details and parameters: G122-824A002 MOOG servo amplifier
Input signal: Supports two single ended signals (± 10V or 4-20 mA) and one differential signal (± 10V).
Output signal: Current output is 0-2 A, voltage output is ± 10V.
Gain adjustment: The adjustable range of proportional gain is 1 to 1000, and the adjustable range of integral gain is 0 to 0.01 s ^ -1.
Lag: 55 ms lag can be selected.
Power requirement: 24 VDC.
Working temperature range: -40 ° C to 70 ° C.
Shell protection level: IP66/NEMA 4X.
Dimensions: 224 mm x 168 mm x 89 mm.
Weight: Approximately 2.7 kg.
Installation method: Supports DIN rail or wall mounting.
G122-824A002 MOOG application areas:

MOOG G122-824A002 is a high-performance servo amplifier widely used in industrial automation, robotics, CNC machine tools, and other fields that require precise motion control. This servo amplifier is renowned for its high amplification and power output capabilities, extensive compatibility with servo motors, advanced control algorithms for precision motion control, and robust structure. It can provide stable current and precise position control, achieving efficient machining processes and production efficiency.
