描述

HONEYWELL LG1093AA24 261A1812P012：高靈敏度紫外線火焰?zhèn)鞲衅?/h3>

品牌：Honeywell
型號：LG1093AA24 261A1812P012
產品參數：

• 傳感器類型：紫外線火焰?zhèn)鞲衅?/div>
• 外殼材質：1.4571 不銹鋼
• 窗口材質：熔融石英
• 安裝方式：3/4 英寸內螺紋
• 工作溫度范圍：-40°C 至 177°C
• 耐壓性：21 bar（300 psi）@ 316°C（600°F）
• 電纜特性：PTFE 材質，橙色護套，引線長度 4.9 米
• 光譜靈敏度：190-290 nm
• 啟動電壓：<260VDC
• 背景噪音：<5 min?1
• 響應時間：<200ms
• 推薦工作電壓：260-350VDC，建議 325VDC±25VDC
• 脈沖輸出：275 次/秒±25 次/秒

Brand: Honeywell
Model: LG1093AA24 261A1812P012
Product Parameters:

• Sensor Type: Ultraviolet Flame Sensor
• Housing Material: 1.4571 Stainless Steel
• Window Material: Fused Quartz
• Mounting Interface: 3/4 inch internal NPT
• Operating Temperature Range: -40°C to 177°C
• Pressure Resistance: 21 bar (300 psi) @ 316°C (600°F)
• Cable Characteristics: PTFE material, orange sheath, lead length 4.9 meters
• Spectral Sensitivity: 190-290 nm
• Start-up Voltage: <260VDC
• Background Noise: <5 min?1
• Response Time: <200ms
• Recommended Operating Voltage: 260-350VDC, suggested 325VDC±25VDC
• Pulse Output: 275 times/second±25 times/second


產品介紹：
Honeywell LG1093AA24 261A1812P012 是一款高性能的紫外線火焰?zhèn)鞲衅?，專為檢測烴類火焰發出的紫外線輻射而設計。它采用先進的紫外線敏感技術，能夠快速響應火焰的存在，并將其轉化為電信號，從而實現火焰的檢測和控制。該傳感器具有高靈敏度、寬光譜響應范圍以及快速響應時間，能夠在各種工業環境中提供可靠的火焰檢測。

Product Introduction:
The Honeywell LG1093AA24 261A1812P012 is a high-performance ultraviolet flame sensor designed to detect ultraviolet radiation emitted by hydrocarbon flames. It uses advanced UV-sensitive technology to quickly respond to the presence of flames and convert them into electrical signals for flame detection and control. The sensor features high sensitivity, wide spectral response, and fast response time, providing reliable flame detection in various industrial environments.

產品應用行業：

• 工業爐窯：監測火焰狀態，確保燃燒穩定。
• 鍋爐：檢測火焰，提高燃燒效率。
• 燃?xì)庠O(shè)備：檢測火焰，確保安全運行。
• 航空航天：用于檢測發動機火焰等。

Product Application Industries:

• Industrial Furnaces: Monitoring flame status to ensure stable combustion.
• Boilers: Detecting flames to improve combustion efficiency.
• Gas Appliances: Detecting flames to ensure safe operation.
• Aerospace: Used for detecting engine flames.
