描述

IC693MDL340 0.5安培交流輸出模塊

IC693MDL340是GE發那科公司生產的90-30系列的120伏，0.5安培交流輸出模塊。它在兩個孤立的組中提供16個輸出點，每組8個輸出點。這些組中的每一個都有一個單獨的公共與它相關聯(兩個公共不集成在IC693MDL340中)，允許每個組與獨立的交流供電相使用?；蛘?，也可以用相同的電源為兩個公共場所供電。每組都有一個3安培的保險絲用于保護，以及一個RC緩沖器用于每個輸出，以保護它們免受電源線的瞬態電氣噪聲的影響。該模塊還具有85至132伏AC, 50/60 Hz的輸出電壓范圍，每點最大輸出電流為0.5安培。每組最大電流為3安培。

IC693MDL340提供高度的浪涌電流，使其輸出適合控制各種負載，包括電感和白熾負載。用戶必須提供交流電源來操作連接到輸出端的負載。本模塊只能在交流電源下工作。IC693MDL340頂部有LED信號燈，用于表示每個點的開/關狀態。此外，它還有兩條水平線，每條水平線上有另外8個綠色LED，兩條線之間的中心有一個LED。頂部的8個led(標識為A1到8)表示輸出狀態。紅色“F”LED打開表示保險絲燒斷。除非有負載連接到熔斷的保險絲上，否則LED將不起作用。

IC693MDL340的特點是一個插入，分離其鉸鏈門的外部和內部表面。此門關閉后，模塊內表面顯示電路布線信息，外表面顯示電路識別信息。插入件的左外邊緣呈紅色，表示為高壓模塊。IC693MDL340模塊可以安裝在系列90-30 PLC系統的5槽或10槽底板的任意I/O插槽中。IC693MDL340在開啟時的最大響應時間為1 ms，最大關閉響應時間為?周期。它的功耗為315 mA(當所有輸出都接通時)，來自背板上的5個電壓總線。

IC693MDL340 0.5安培交流輸出模塊

The IC693MDL340 is a 120 volt, 0.5 Amp AC Output Module of the Series 90-30 manufactured by GE Fanuc. It provides 16 output points in two isolated groups with eight points in each. Each of these groups has a separate common associated with it (the two commons are not integrated inside the IC693MDL340), allowing each group to be used with independent AC supply phases. Alternatively, it is also possible to power both commons with the same supply. Each group has a 3-ampere fuse for protection, as well as an RC snubber for each output to guard them against transient electrical noise from the power line. This module also has an output voltage range of 85 to 132 volts AC, 50/60 Hz, and an output current of 0.5 amperes maximum per point. The maximum per group is 3 amps.

IC693MDL340 provides a high-degree of inrush current, making its outputs advisable for controlling a great variety of loads, both inductive and incandescent. The user must provide an AC Power supply to operate the loads connected to outputs. This module can only function on an AC power source. IC693MDL340 has LED signaling lights at the top, designed to represent the ON/OFF status for each point. Additionally, it also has two horizontal lines with another eight green LEDs each, and one final LED at the center between the two lines. The eight LEDs at the top, which are identified as A1 to 8, indicate output status. The red “F” LED turns on to signal a blown fuse. Unless there is a load connected to the blown fuse, the LED will not function.

IC693MDL340 features an insert that separates its hinged door’s external and internal surface. Once this door is closed, circuit wiring information is shown the inside surface of the module, and circuit identification information can be found on the outside surface. The external left edge of the insert is colored red to indicate a high-voltage module. IC693MDL340 module can be installed in any I/O slot of a 5 or 10-slot baseplate in a Series 90-30 PLC system. IC693MDL340 has a response time of 1 ms maximum when ON and a maximum off response time of ? cycle. It has a power consumption of 315 mA (when all outputs are on) from 5 voltages bus on backplane.
