描述

IC693MDL734 正邏輯/負邏輯和 1 安培輸出的 125 伏直流模塊

IC693MDL734 是一款具有正邏輯/負邏輯和 1 安培輸出的 125 伏直流模塊，是 GE Fanuc Automation 制造的系列 90-30 可編程邏輯控制器的組件。該模塊提供 6 個帶電源輸出端子的隔離點輸出。該設計的雙重特性為用戶提供了使用正邏輯（其中電流來自公共用戶或正供電終端總線）或負邏輯（其中電流來自公共用戶負載或負供電終端總線）的選項。該模塊具有正邏輯和負邏輯選項，可與各種輸出設備兼容?，F(xiàn)場設備使用兼容的用戶提供的電源運行。

為了傳達每個輸出電路的ON/OFF狀態，每個點都有相應的LED指示燈。所有這些 LED 指示燈均位于模塊的頂部表面。LED 燈排列成兩行。六個 ON/OFF 狀態指示燈為綠色，位于第一行，標記為 A1 至 A6。電路布線位于模塊門板的內表面，而識別電壓類型的信息則位于另一側。IC693MDL734是高壓模塊，如插入件左側邊緣附近標記的紅色顏色編碼方案所示。該嵌件安裝在門板的內表面和外表面之間。建議設置外部熔斷器。

系列 90-30 PLC 系統包含在 5 插槽基板或 10 插槽基板中。IC693MDL734 可以安裝到任何 I/O 插槽中。IC693MDL734 的額定電壓為 125 VDC，有 6 個隔離輸出，活動時每點最大輸出電流為 1mA。IC693MDL734 上的所有輸出均通過 5 伏電源消耗 90mA 功耗。

技術規格
額定電壓： 125伏直流電
輸出數量： 6（孤立）
頻率： 不適用
輸出負載： 每點 1.0 安培
輸出電壓范圍： -10.8 至 +150 伏直流電
直流電源： 是的

IC693MDL734 正邏輯/負邏輯和 1 安培輸出的 125 伏直流模塊

The IC693MDL734 is a 125-volt DC module with positive/negative logic and 1 amp output and is part of a series of 90-30 programmable logic controllers manufactured by GE Fanuc Automation. The module provides 6 isolated point outputs with power output terminals. The dual nature of the design gives the user the option of using either positive logic (where the current comes from a public user load or a positive powered terminal bus) or negative logic (where the current comes from a public user load or a negative powered terminal bus). The module has positive and negative logic options and is compatible with various output devices. Field equipment runs on a compatible user-supplied power supply.

In order to convey the ON/OFF status of each output circuit, each point has a corresponding LED indicator. All of these LED indicators are located on the top surface of the module. The LED lights are arranged in two rows. The six ON/OFF status indicators are green and located in the first row, labeled A1 to A6. The circuit wiring is located on the inner surface of the module door panel, while the information identifying the voltage type is located on the other side. The IC693MDL734 is a high voltage module, as indicated by the red color coding scheme marked near the left edge of the insert. The insert is installed between the inner and outer surfaces of the door panel. An external fuse is recommended.

The series 90-30 PLC system is included in either a 5-slot substrate or a 10-slot substrate. The IC693MDL734 can be installed into any I/O slot. The IC693MDL734 is rated at 125 VDC and has 6 isolated outputs with a maximum output current of 1mA per point when active. All outputs on the IC693MDL734 consume 90mA via a 5 volt supply.

Technical specification
Rated voltage: 125 volts DC
Output quantity: 6 (isolated)
Frequency: Not applicable
Output load: 1.0 amps per point
Output voltage range: -10.8 to +150 volts DC
Dc power supply: Yes
