描述

IC695ALG508CA RTD 輸入模塊

IC695ALG508是一款電阻溫度檢測器(RTD)輸入模塊，是PACSystem RX3i可編程自動化控制器(PAC)平臺的一部分。該模塊由艾默生自動化公司生產，前身為GE智能平臺公司(GE IP)。它配備了8個隔離差分輸入通道，支持RTD和電阻輸入的直接輸入。

該模塊支持RTD輸入類型，如50,100,200,500和1000歐姆白金385 (IEC751 1983，修訂2 1995;Jisc 1604 1997);50,100,200,500和1000歐姆鉑391.6 (JISC 1604: 1981);100歐姆，200歐姆，500歐姆和1000歐姆鎳618 (DIN 43760 september 1987);120歐姆鎳672 (MINCO應用援助#18,5/90型Ni);10, 50和100歐姆銅426 (SAMA RC21-4-1966)和604歐姆鎳鐵518。而支持的電阻輸入是0-260,0-525,0-1050,0-2100,0-3150,0-4200歐姆。

該模塊具有可選的測量單位，具體來說，攝氏度，華氏度或歐姆。它還具有可配置的默認或保持最后狀態，作為對系統故障和CPU操作模式更改的反應。該模塊支持兩線制、三線制和四線制RTD傳感器。

IC695ALG508的輸入數據格式支持32位字段中的16位整數或32位IEEE浮點數據。每個通道還配有2.3 Hz至28 Hz的可選陷波濾波器設置。對于輸入線的終端，該模塊使用盒式(IC694TBB032)，擴展盒式(IC694TBB132)，彈簧式(IC694TBS032)或擴展彈簧式(IC694TBS132)端子座。對于屏蔽布線，推薦使用擴展端子塊類型，因為這些塊提供額外的覆蓋深度。

GE Fanuc IC695ALG508電阻溫度檢測器(RTD)輸入模塊提供8個隔離差分RTD輸入通道。每個通道可以單獨設置為RTD輸入類型或電阻輸入類型。RTD輸入類型的電阻額定值包括1000、500、200、100和50歐姆，1000、500、200、100和50歐姆，1000、500、200和100歐姆，120歐姆，604歐姆，或100、50和10歐姆，具體取決于它們的材質。電阻輸入類型包括額定電阻4000、3000、2000、1000、500和250歐姆。該RTD輸入模塊可與端子排一起使用，包括彈簧式IC694TBS032端子排、擴展彈簧式IC694TBS132端子排、箱式IC694TBB032端子排或擴展箱式IC694TBB132端子排。接線端子通常需要單獨購買。

GE Fanuc IC695ALG508 RTD輸入模塊有OK指示燈顯示模塊狀態，F(xiàn)ield status指示燈顯示是否有外部24伏直流供電、電壓是否超限、是否存在故障等。背板電源總線為模塊的所有l(wèi)ed供電。IC695ALG508模塊每個通道都有一個可編程陷波濾波器，頻率在2.3赫茲到28赫茲之間。每個通道都有一個32位IEEE浮點數據或16位整數數據的可選輸入數據濾波器。IC695ALG508模塊在ITS-90上制定了RTD線性化。該模塊位于RX3i通用背板中。它的工作溫度范圍為0至60攝氏度，儲存溫度范圍為-40至85攝氏度，非冷凝濕度范圍為5%至95%。

IC695ALG508CA RTD 輸入模塊

The IC695ALG508 is a Resistance Temperature Detector (RTD) input module that is part of the PACSystem RX3i Programmable Automation Controller (PAC) platform. This module is manufactured by Emerson Automation, formerly by GE Intelligent Platforms (GE IP). It comes with Eight (8) isolated differential input channels and supports direct input of RTD and resistance inputs.

This module supports RTD input types such as 50, 100, 200, 500, and 1000 ohm Platinum 385 (IEC751 1983, Amend 2 1995; JISC 1604 1997); 50, 100, 200, 500, and 1000 ohm Platinum 391.6 (JISC 1604: 1981); 100 ohm, 200 ohm, 500 ohm, and 1000 ohm Nickel 618 (DIN 43760 Sept. 1987); 120 ohm Nickel 672 (MINCO Application Aid #18, 5/90 Type Ni); 10, 50, and 100 ohm Copper 426 (SAMA RC21-4-1966) and 604 ohm Nickel-Iron 518. While the supported Resistance inputs are 0-260, 0-525, 0-1050, 0-2100, 0-3150, 0-4200 ohms.

This module has selectable measurement units, specifically, Degrees Celsius, Degree Fahrenheit or Ohms. It also has configurable default or hold last state as a reaction to system failure and CPU change of operating mode. This module support Two-Wire, Three-Wire and Four-Wire RTD sensors.

The IC695ALG508 input data format supports 16-bit integer in 32-bit field or 32-bit IEEE Floating point data. Each channel also comes with selectable notch filter settings from 2.3 Hz to 28 Hz. For termination of input wires, this module uses Box-style (IC694TBB032), Extended Boxstyle (IC694TBB132), Spring-style (IC694TBS032), or Extended Spring-style (IC694TBS132) Terminal Block. For shielded wiring, the extended terminal block types are recommended for use as these blocks provide extra shroud depth.

The GE Fanuc IC695ALG508 Resistance Temperature Detector (RTD) input module offers 8 isolated differential RTD input channels. Every channel can be separately set up as an RTD input type or a resistance input type. The RTD input types include resistance ratings of 1000, 500, 200, 100, and 50 Ohms, 1000, 500, 200, 100, and 50 Ohms, 1000, 500, 200, and 100 Ohms, 120 Ohms, 604 Ohms, or 100, 50, and 10 Ohms depending on what they are made of. The resistance input types include resistance ratings of 4000, 3000, 2000, 1000, 500, and 250 Ohms. This RTD input module can be used with terminal blocks including the spring-style IC694TBS032 terminal block, the extended spring-style IC694TBS132 terminal block, the box-style IC694TBB032 terminal block or the extended box-style IC694TBB132 terminal block. The terminal blocks usually need to be purchased separately.

The GE Fanuc IC695ALG508 RTD input module has LEDs that include the OK LED that shows the status of the module while the Field Status LED shows if an external 24 Volts DC power supply is connected, whether the voltage is exceeding the minimal level, and also if any faults are present or not. The backplane power bus powers all the LEDs for the module. The IC695ALG508 module has a programmable notch filter frequency between 2.3 Hertz and 28 Hertz for every channel. Each channel has a selectable input data filter with 32-bit IEEE floating point data or 16-bit integer data. The IC695ALG508 module has RTD linearization formulated on the ITS-90. This module is found in the RX3i Universal backplane. It has an operating temperature range of 0 to 60 degrees Celsius, a storage temperature range of -40 to 85 degrees Celsius, and a non-condensing humidity range from 5 percent to 95 percent.
